Food online > Products > Food Processing Machinery > Production Line >

1-5 Gallon Pure Drinking Water Bottling Plant,China JIAYUAN price supplier

1-5 Gallon Pure Drinking Water Bottling Plant

FOB Price:Price can be negotiated

Update Time:2025-04-11

Contact Supplier

Product Description

1-5 Gallon Pure Drinking Water Bottling Plant

1.Production capacity:300b/h

2.Electrical Equipment:PLC

3.Efficient,good price and low cost barrel water bottling line

Application:

1. Specially produces 3-5 gallons barreled drinking water

2.100 type, 150 type, 200 type, 300 type, 450 type, 600 type, 900 type, 1200 type.

3.Including bottle washing, filling and capping into one unit(3-IN-1)

4.In order to achieve the purpose of washing and sterilizing. The washing machine uses multi-washing liquid spray and-thimerosal spray. This thimerosal can be used circularly.

5.The capping machine can cap barrel caps automatically. This line equips with water spraying device in order to ensure those caps sterile and clean.

6.It also can automatically carry out barrel, washing, sterilizing, filling, capping, counting and products discharging, with complete function, modern design and high degree of automation.

7.It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.

Main parameters:

Model	QGF-120	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200	QGF-2000
Filling heads	1	2	3	4	8	12	16
Volume(L)	18.9	18.9	18.9	18.9	18.9	18.9	18.9
Barrel size(mm)	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490
Capacity(B/n)	100-200	200-240	300-400	600	900	1200	2000
Gas pressure(mpa)	0.4-0.6	0.4-0.6	0.6	0.6	0.6	0.6	0.6
Gas consumption (m³/min)	0.37	0.6	0.6	1.2	2.2	3	4.5
Motor power(Kw)	1.75	3.22	4.8	8.5	8.5	8.5	8.5
Rated votage(V)	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz
Outline dimension(mm)	3970×650×1550	3550×800×1800 2800×1100×1800	3550×1200×1800 3800×1100×1800	3650×1500×1800 3800×1100×1800	2200×1860×2700	2560×2350×2750	3100×2800×2750
Weight(kg)	800	2800	4000	5500	7500	9500	11800

Other Products

Bottled Water filling Machine/Production Line/Water Filling Equipment

1-5 Gallon Pure Drinking Water Bottling Plant

Automatic Carbonated Drinks Filling Machine

Automatic Hot Juice Making Machinery

Company Profile

Name: Zhangjiagang Jiayuan Machinery Co.,Ltd

Main Products: carbonated and non-carbonated beverage production line, pure water production line, juice, tea and alcohol and other liquids packed in bottle, barrel, can, glass, and others production lines.

Total Employees: 50 ~ 100

Established Year: 2011

Total Annual Revenue: US$50 Million - US$100 Million

Main Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe,

Address: No.198, Zhenbei Road, Leyu Town

Professional filling machine manufacturer---Zhangjiagang Jiayuan Machinery Co.,Ltd. is a professional beverage machinery manufacturer to produce beverage machine and water treatment equipment. Our business philosophy is market-oriented, technology-guided, quality-based and customers-first. We now have passed ISO9001 international quality management system certification and own a perfect quality guarantee system.The main products of our company contain: carbinated and non-carbinated beverage production line, pure water production line, juice ,tea and alcohol and other liquids packed in bottle, barrel,can, glass, and others production lines. With an experienced and professional team, we have exported our products to many countries and regions all over the world. Our products enjoy a good reputation among our customers. We sinerely welcome customers, business associations and friends from all parts of the world to contact us and seek cooperation for mutual benefits.
