-150'C High Quality SSD IQF tunnel Seafood Iqf Machine for Sardine fillet
reduce the damage of the product cell structure
-150'C High Quality SSD IQF tunnel Seafood Iqf Machine for sardine fillet Oyster
Introduction of liquid nitrogen quick freezer:
Liquid nitrogen freezing is mature freezing technology,due to the ultra low temperature
-196'C,such fast freezing, generating the smallest ice crystals, and helps maintain food
texture;Which the traditional can not done like that.Meanwhile,it also prevents water loss,could
improve the rate of finished products,promote the corporate image.but the traditional quick
freezing equipment will lost 3%-5% moisture of food.And it can adjust the output of seafood,
decrease the maintain work, it is good choice to buy for food freezing factory
Liquid nitrogen freezer Application: frozen food industry: freezing the seafood, meat and fresh vegetable.ready meal
Technical Parameter:
| Tunnel IQF Freezer(SD-G-300KG/H) |
composition as follow |
| Insulation box |
Including the box, door, thermal-protective coating made of stainless steel AISI 304 |
| Internal surface roughness |
Matte |
| Insulation materials |
ultra-low temperature thermal insulation materials Made in Germany BASF |
| The door sealing |
double sealing , one is low temperature silica gel , at the place of the door sealing, have the Antifreeze death system(Domestic unique) |
| Liquid nitrogen freezer |
Technical parameter |
| Quick-frozen quantity |
500 kg/ hour; |
| Working temperature |
room temp. 120 ~-190°C, you can adjust the temp.as your need
|
| Lowest temperature inside |
-190°C |
| Max cooling rate |
0~20°C/min ,adjust the temp as you need |
| Insulation thickness |
150mm. Ensure the surface is in room temperature |
| Liquid nitrogen system |
Including insulation tubes, control valves, nozzles, and distributors, liquid nitrogen use the multi-point injection into the well to ensure the uniformity of the body temperature |
| liquid nitrogen valve |
ASCO ( imported From America )open normally in -196 °C. |
| low noise axial flow fan |
return air from short, freeze fast and efficient way than the normal freezing increased by 40% -65% |
| wind speed and temperature of the frozen zone |
more uniform, stable, and air duct to reduce the losses of air resistance, reduced fan power, reducing the consumption of cold.
|
| Air circulation system inside |
i ncluding motors, fans, air distribution devices |
| Discourage micro-pressure valve |
when pressure inside is positive Pressure, the valve will work automatically |
| Control system |
variable program controller, touch screen, PLC, alarm meters AC contactor, relay, rotary switch, etc |
| touch screen + PLC control mode |
you will have a realtime monitoring of temperature inside |
| lock cylinder unit |
ensure that the door does not leak air out |
| An alarm device |
alert when the door is not closed. |
| Two control system: |
manual and automatic. A PID regulator can ensure the precision. |
| operating system |
the system will automatically cool down by technology curve, insulation, and other activities out of the bo |
To make a fast and detailed quotation, we would like you to give us the answer as follow:
1.What product do you want to freeze?
2.Do you have requirement for the freezing temperature?
3.How many kilogram will be frozen per hour?
4.What is your voltage/phase/frequency in your country?
We also manufacture the cryogenic iqf freezer based on your requirement
| Product/Service (We Sell): | Cryogenic Equipment,Freezer | |
| Number of Employees: | 11 - 50 People |
| Main Markets: | Southern Europe Eastern Europe Central America Western Europe South America Eastern Asia Oceania Africa North America Northern Europe Mid East Southeast Asia |
|
| Total Annual Sales Volume: | US$2.5 Million - US$5 Million | |
| Export Percentage: | 31% - 40% |
| Factory Size (Sq.meters): | 1,000-3,000 square meters | |
| Factory Location: | Team One, West Of Hengqiao Village, Machikou Town, Changping District | |
| Number of Production Lines: | 3 | |
| Number of R&D Staff: | 11 - 20 People | |
| Number of QC Staff: | 11 - 20 People | |
| Contract Manufacturing: | OEM Service Offered |
| Condition: |
New
|
Type: |
box type
|
Place of Origin: |
Beijing China (Mainland)
|
| Brand Name: |
cryogenic
|
Model Number: |
SD-500H
|
Voltage: |
220V/380V
|
| Power(W): |
0.37
|
Dimension(L*W*H): |
6000*1380*1800mm
|
Weight: |
500KG
|
| Certification: |
CE
|
Warranty: |
All life
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
| material: |
stainless steel
|
Work temperature: |
+120~-150℃
|
The frozen capacity: |
200KG
|
| Cooling rate: |
1~50, can be set arbitrarily
|
