cocoa bean grinding Machine
1.all 304# stainless Steel made
2.low noise,high performance
3.fine powder process
4.CE approved
2014 low noise high quality cocoa bean grinding machine
Processing range of cocoa bean grinding machine:
1 cocoa beans, walnuts, rice, black rice, soybeans, mung beans, peanuts, seeds, corn, sorghum, barley, buckwheat, oats, etc.;
2 kinds of dry herbs with almonds, Poria, dates, Gorgon, wolfberry, barley, hawthorn, yam, Radix, red beans, gelatin, frankincense, dodder seed, angelica, Codonopsis, Astragalus.
The character of the cocoa bean grinding machine:
1. When working, it relies on the millstones to make the goods into powder. This machine can realize continuous feed-type operation.
2. Its unique design, low noise level, easy operation, crushed fine, dust-free have won lots of praise of our customer.
3. It is a good choose for supermarket, store, processing shop...etc. Made of stainless steel, this type machine can realize durable use life.
The Technical datas of cocoa bean grinding machine:
1.small type:
Model |
Voltage |
Power |
Capacity |
Fineness |
Dimension |
Weight |
FX-810 |
220v |
1.1kw |
20-40kg/h |
50-200mesh |
470*220*340mm |
28kg |
FX-820 |
220v |
1.8kw |
40-50kg/h |
50-200mesh |
650*300*450mm |
40kg |
FX-830 |
220v |
2.2kw |
45-65kg/h |
50-200mesh |
550*260*430mm |
40kg |
2.Big type:
Model |
FR- 180 |
FR- 250 |
FR- 320 |
FR- 350 |
Machine material |
Stainless steel |
|||
Voltage |
220V/380V |
380V |
380V |
380V |
Power |
2200W |
5500W |
7500W |
11000W |
Rotating speed |
4200r/m |
4200r/m |
4200r/m |
4200r/m |
Fineness |
10-120mm |
10-120mm |
10-120mm |
10-120mm |
Productive capacity(kg/h) |
30-120 |
60-200 |
80-300 |
100-500 |
Overall size(mm) |
480*520*1040 |
750*600*1260 |
780*700*1350 |
800*900*1550 |
Weight |
80kg |
180kg |
260kg |
320kg |
Matter need attention as below:
1. Each machine after use should be clean inside the cocoa bean grinding machine, and air dry.
2. Whenever the machine parts, such as severe wear or damage should be promptly repaired or replaced.
3. Longer period of time the machine when not in use,the machine not to invert,to flat,do not put heavy objects on top.
4. The cocoa bean grinding machine should be placed at the counter or stable on the desktop,plus screws.
5. The cocoa bean grinding machine starts , should be operating normally ,to discharge processing ,attention to feeding quantity boring machine to prevent motor overload.
6. In the process,such as a sudden shutdown because of power failures and other reasons,you must clear the grinding chamber (or room or splintered the chamer)within the material to re-start.
7. Whole grains,dried Chinese herbal medicines, clear stones, metal and other debris.
8. Ground wire in accordance with the provisions
9. Should be in accordance with the provisions of the direction of motor operation .
10. Do not head above the ballast, so as not to drive shaft deformation.
Place of Origin: |
Henan China (Mainland)
|
Brand Name: |
FUSION cocoa bean grinding machine
|
Model Number: |
FX-series cocoa bean grinding machine
|
Type: |
Grain Processing Equipment
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
model: |
FX-820 cocoa bean grinding machine
|
capacity: |
40-50kg/h
|
power: |
1.8kw
|
diemension: |
650*300*450mm
|
weight: |
40kg
|
material: |
304 stainless steel
|
spare parts: |
disc,millstone
|
fineness: |
50-200mesh
|
voltage: |
220v/50hz or 380v
|
cetificate: |
CE
|
