24 rails high precision fast speed Photoelectric counting chewing gum machine with Netherlands techn

FOB Price:Price can be negotiated

Production Capacity:120 Unit/Units per Year

Payment Terms: US $100,000 - 133,000 / Unit

Update Time:2014-09-25

Contact Supplier

Product Description

1.fast speed,high efficient
2.high precision
3.high technology from Europe and America
4.full automatic

SLJ-12 Photoelectric tablet counting machine

features

Counting device consists of cutting the channel, counting electric eye detection systems,

material door control system components. Each channel can be individually few Grains of action,

can be used to count the number of fewer than 12 special column settings.

Stock bin is a tapered body store used for drug grain warehouse .

The operator can easily see how much drugs grain in stock bin from all directions at all times

to determine whether feeding.

blanking hopper including the discharge hopper,total discharge door and nozzle system three parts.

The entire device is fixed by the positioning block at the bottom of the upper part of the body.

Join institution in the rear section of the Conveyor belt, mainly by three electric eyes of blocking bottles

and two cylinder of bottle stopper components.through the cylinder block control both sides,the bottle are put in turn.

Three grade Vibration plate supply system consists of drug delivery path, vibrators and track positioning cylinder components.

Three grade vibration plate supply system to take a modular design, installation and removal is very convenient and simple.

There is a disk for culling at both sides of conveyor belt, each group of culling disk is controled by separate solenoid valve.

The culling disk used to store the cull bottle.

main technical parameter:

model	Max speed (grains/min)	single bottle	Common type	Medcine size	Bottle diameter (mm)	Bottle height	voltage	Air compressed (MPa)	Total power (kw)	Exteral size (mm)	Machine weight (kg)
SLJ-12	7200	3-10000 grains	Pills, tablets, hard and soft capsules and tablets cured drugs	¢ 1.5-30MM ¢ 1.5-30MM pills, tablets and a variety of hard and soft capsules and tablets of other curing agents	¢ 10-100	20-240 (mm)	220V 50/60HZ	0.5-06	1.5	136017002000	580
SLJ-24	14000	3-20000 grains			¢ 10-100	20-240 (mm)	220V 50/60HZ	0.5-06	2.2	176018002000	960

if you are intereste in it,plz feel free to contact me.

let me know your capacity requirement and bottle size.

then I can offer you more details and information.

alice cell:+8613810983151 skype:alice.bjhy

Type:	Other	Condition:	New	Application:	Chemical,Food,Medical,capsule,tablet,pill,grain,Pills, tablets, hard and soft capsules and tablets cured drugs
Packaging Type:	Bottles	Packaging Material:	Glass,Metal,Plastic	Automatic Grade:	Automatic
Driven Type:	Pneumatic	Voltage:	220V 50/60Hz	Power:	1.5kw
Place of Origin:	Beijing China (Mainland)	Brand Name:	HuaYuan	Model Number:	SLJ-12
Weight:	580KG	Dimension(LWH):	136017002000mm	After-sales Service Provided:	Engineers available to service machinery overseas
name:	SLJ-24 Photoelectric tablet counting machine	model:	SLJ-12	max speed:	7200grains
grains diameter:	1.5-30mm	bottle diameter:	10-100mm	bottle height:	20-240mm
working principle:	photoelectric	material:	stainless steel	technical:	Europe and America
