3-layer vertical mixing tank series

Applicable range:

 mixing tank is used as liquid storage tank,liquid mixing tank, ect.Agitator Vessel Applies to fields such as foods, dairy products, fruit Juice beverages.

Structure Characteristics:

1.Mixing tank adopts structure of single-layer with sanitary material of ss304. as optional, stainless steel tank can be dual-layer with jacket and three-layer with heating and cooling jacket and insulation.

2.Materials are all sanitary stainless steel. as option, it is can be ss304 or ss316 which are all food grade.

3.Humanized structure design and easy to operate. Transition area of interior wall on tank adopts arc for transition to ensure no dead corner of sanitation.the inner shell of vessel will be 3A polish(mirror polish) for easy cleaning. the outer shell will be 2B polish( satin polish) for beauty appearance.

4.as to the agitator, it is paddle design. as to the motor, it is ABB. as to option, it can be SEW or Siemens.

5.as to the bottom, it can be conical for easy liquid out.

6.we also equip the tank with control panel. it will be used for control the speed, temperature displaying and so on.

Configuration of tank: 1) Manhole 2) CIP cleaner 3) Adjustable triangle bracket 4) Ladder 5) Thermometer 6) Liquid lever meter and controller 7) Eddy-proof board 8) Dismountable Inlet assembly 9) Sanitary breathing cover10)vetical Mixer

working volume
(L) dimension of tank
(mm*mm) total height
(mm) diameter of inlet&outlet
(mm)
1500 1160*1500 3350 51
2000 1340*1500 3410 51
6000 1980*2000 4550 51
10000 2300*2440 5050 51
20000 2640*3660 6400 51
working volume
(L) motor power
(kw) heat preservation layer
(mm) Blending speed
1500 0.75 80 common rotation speed
35,43,60.
stepless speed reducer
or dual-speed reducer
are also available
