Sensitive
Easy to use
Easy to tidy up
Suitable for different usages
Color,size and material are all possibly tailor made
Instructions:
1) Place the sensor pad on the bed, under the buttocks or shoulder area of the user. *
2) When the staff remove the user from the pad, the monitor will produce sounds. ^
3) Press the button " Text/Reset " on the monitor can stop the sound and reset the sensor pad.
Remarks:
*It must be directly put on the mattress, under the sheet.
^The Bed Sensor Pad must be used with a monitor, any types of monitor from our company are suitable for matching with the sensor pad.
How to test the Pad:
1) Activate the Monitor.
♦ If your monitor has an on/off switch, turn it on.
♦ If your monitor does not have an on/off switch, pressure on the sensor pad and it will automatically turn on.
2) Press down on the pad and then release, if the alarm sounds, the unit is operational.
3. Turn the monitor OFF or press the reset button.
Cleaning Instructions:
Use a non-caustic sanitizing solution to wipe clean when necessary.
Attention:
1. Do not fold or immerse the sensor pad in any solution.
2. To minimize spreading of infection, single patient use is recommended.
Place of Origin: |
Guangdong China (Mainland)
|
Brand Name: |
Contin
|
Model Number: |
WC-B365-NC10
|
Color: |
White
|
Size: |
30" x 10", or for your reference
|
Life Time: |
45 days, 90 days, 180 days, 1 year
|
Coat Material: |
0.2mm,0.25mm,0.5mm PVC, or for your reference
|
Resistance: |
< 1k OHM
|
Cord: |
Cord or Cordless
|
Plug-in: |
Tel., Mono, Stereo
|
Pattern: |
Plain
|
