lollipop wrapping Stretch Film machine
1) Automatic winder
2) Speed: 100kg/h
3) Total power: 92kw
500-1000mm lollipop wrapping Stretch Film machine
Product introduction
Use:
1) The most usage pallet packaging: Such as fertile, cement, chemicalindustrial raw material, building material etc.
2) Horizontal packaging: Metal pipe, aluminum alloy material, timber etc.
3) Rotational twist: Rolling paper, carpet etc.
4) Binding: Glass container, acceptance etc.
5) Break-bulk packaging: Soybean, grain, plastic particle etc.
6) Storage packaging: Such as grass.
7) Manual packaging: It is used in wholesales, journal, printing, electronic product, foodstuff etc.
8) Ring twist packaging: Type, wire, cable, steel silk etc.
Finished Products of Stretch Cling Film Machine:
It is a very good kind of packaging material mostly used in the industrial field,port pallet packaging,,building material packaging, hardware packaging etc.It enjoys the following advantages:
1) Good tensile strength
2) Superior anti-pricking ability
3) High transparency
4) Good ductility and anti-impact strength
5) Stable sticky sides etc
Outstanding Features of Aoxiang Stretch Cling Film Machine:
1) Higher output with stable quality stretch film,superior than the same suppliers more than 30%.
2) Higher speed with good ideal tensil and anti-pricking stretch film, which make sure the machine make big output.
3) Good water cooling effect and imported die steel to ensure making even and good ductility stretch film.
4) Swing system installed to adjust the film thickness and evenness.
5) The alloy screw adopts special mixing function and high plasticizing design which combine import static Mixer to ensure plasticization is great, color is uniform and increase extrusion capacity greatly.
6) PLC controlled,fully automatic.
Main Technical Variables:
Item/Model |
1250 (mm) Two layer |
Screw diameter(mm) |
55 (1 piece) 65(1 piece) |
L/D ratio of screw (L/D) |
30 : 1 |
W idth of die head (mm) |
1000 |
Width of finished products(mm) |
1000or500*2 |
Thickness of finished products (mm) |
0.0 12 -0. 05 |
Structure of film layers |
A / B |
Max output (kg/h) |
80-100 |
Linear speed of machinery (m/min) |
50-100 |
Traction power (kw) |
2.2*2 |
Production speed (m/min) |
60 |
Total power (KW) |
78 |
Weight (T)(About) |
4.5 |
Overall dimensions (L*W*H)m |
7*2.3*2.3m |
Condition: |
New,new
|
Application: |
Profile,film
|
Plastic Processed: |
PE
|
Screw Design: |
Double-screw
|
Automatic Grade: |
AUTOMATIC,automatic
|
Place of Origin: |
ZHE,zhejiang,ruian China (Mainland)
|
Brand Name: |
Ruian Aoxiang,AX
|
Model Number: |
DF-65/DF-75
|
Voltage: |
380V/50HZ
|
Power(W): |
70KW
|
Dimension(L*W*H): |
7*2.3*2.3M
|
Weight: |
4.5T
|
Certification: |
CE
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Colour: |
Green
|
Automatic reimming device: |
1 pcs
|
control: |
PLC
|
