Tube Ice Machine Brief Introduction:
ALLCOLD engineers designed the unique Tube-Ice Machine specifically to freeze ice automatically in vertical tubes, momentarily thaw ice loose from the tubes and then cut it into short cylinders with a hole in the center. The hole in the ice cube is formed during the formation of the ice as a result of the falling film of water freezing inside the vertical tubes.
Advantage:
a.Delicate welding technics with X-RAY.
b.Remove impurities in the water with special technology.So the ice is hard and never leak.
c.All the material meet the HACCP request.
d.All the running status playing live in touch-screen,convenient as your family air-conditioning.
e.As soon as ice off,the water of low temperature is using for ice-making,which saving energy and increasing the drum volume of production of ice.
f.Perfect failure &trouble-shooting querying system with red warning signal flicker if any failure occurred.
e.Stop-time could be set at your will.
Applications:
1.Edible ice factory
2.Cafes,Bars,hotels and other places which need ice.
3.Thermal Energy Storage/Concrete Cooling
4.Baking Industry Applications/ Chemical and Dye processing.
5.Fish/Seafood icing
6.Logistics preservation
7.Ports Ice Factory
Options:
1.Ice diameter:22mm/28mm/32mm/38mm/41mm
2.Cooling method:Water cooled/Air cooled
Tube Ice Machine Models&Specifications:
| ALLCOLD Tube Ice Machine Models&Specifications | ||||
| Model No.() | Production Capacity kg/24hrs() |
Ice Temperature oC() |
Total Power kW() |
Machine Size mm() |
| ATM-1T | 1,000 | -5 | 8 | 1,400x1,200x1,800 |
| ATM-2T | 2,000 | -5 | 12 | 1,600x1,200x2,000 |
| ATM-3T | 3,000 | -5 | 15.5 | 1,700x1,450x2,000 |
| ATM-5T | 5,000 | -5 | 23.5 | 1,700x1,700x2,200 |
| ATM-8T | 8,000 | -5 | 30 | 2,000x1,750x2,200 |
| ATM-10T | 10,000 | -5 | 45 | 2,900x2,280x2,600 |
| ATM-15T | 15,000 | -5 | 60 | 3,250x3,000x4,200 |
| ATM-20T | 20,000 | -5 | 85 | 3,500x3,350x4,200 |
| ATM-25T | 25,000 | -5 | 95 | 3,850x3,650x4,200 |
| ATM-30T | 30,000 | -5 | 110 | 4,250x3,650x4,200 |
| ATM-40T | 40,000 | -5 | 150 | 5,100x4,700x4,200 |
| ATM-50T | 50,000 | -5 | 180 | 6,000x6,000x4,500 |
ALLCOLD will design and offer the most suitable machine according to clients'requirements.
Please contact ME to get more technical information"ations.
Business Field Of Us:
1.Vacuum Cooler For Vegetables/Flowers/Fruits
2.Cooked Food Vacuum Cooler
3.Modified Atmosphere Packaging Machine(MAP Machine)
4.Tube Ice Machine
5.Flake Ice Machine
6.Block Ice Machine
7.Plate Ice Machine
8.Cold Room
The benefits of choosing us:
1.As a mature manufacturer of fresh keeping technology and refrigeration technology.Our products quality are guaranteed, energy saving and high efficiency.
2.As a responsible manufacturer, we will attentively manufacture each machine.Your request makes us improve,and your satisfaction is our eternal pursue.We will meet customers' demands from various professional fields with first-rate products and services.
3.Safety protection products and environmental-friendly design to reduce greenhouse gas emissions.Here at ALLCOLD we have worldwide sourcing ability and creat great future .
4.Grown Together and make win-win success with clients and cooperative partners.
ALLCOLD Refrigeration is the most professional manufacturer of Vacuum cooling systems and ice making machines in Asia, allcold also specialized in designing and manufacturing of high quality ice making machines(Tube ice machine, flake ice machine, block ice machine, and plate ice machine) We have earned the position of dependable supplier among a vast global clientele due to consistency in quality of our product range and services offered to the clients.
As a well established manufacturer and exporter, we lay special attention to our manufacturing process and delivery of products: Tube ice machine, flake ice machine, block ice machine, and plate ice machine. We take utmost care of quality at every stage of the manufacturing process. Our staff of highly qualified engineers combines the benefits of irreplaceable practical experience with the sophisticated accuracy of our own interactive graphics computer system enable us to provide high quality product, prompt deliveries, dependable service, and outstanding customer satisfaction.
ALLCOLD is known across the world for our high quality equipments and our quality controls sy. We have a hi-tech production unit that uses the latest technology and the most modernized machinery. We have a strong and proficient workforce, comprising of technically skilled professionals and efficient workers. Our research and development wing is our asset that develops and incorporates innovative ideas and products.
Our products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine are globally known for their dimensional accuracy, high efficiency & durability and they are used in various fields such as aquatic food processing, supermarkets, healthcare centers, man-made skiing resort, mines, large-scale concrete construction, etc. The product model ranges from small-sized ice machines with a daily output of 230kgs to large-sized sets of ice making system up to 60tons in 24hours and 85% of our ice making machine' S components are imported and all undergo rigorous monitoring and quality control system to ensure superb quality of our flake ice machine, cube ice machine, tube ice machine, and block ice machine.
We pride ourselves on quality, service and pricing, and believe that all three areas are equally important to ensure the long-term success of your overseas purchasing program. Our sustained relationship with customers serves as testimonial for our high quality products. The fusion of superior quality and reasonable prices make our products capable of influencing anyone in the whole world. Our reputation in the market is synonymous with high quality, updated technology and dedicated approach.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
