Aluminum foil container machine CTJF-60T,China choctaek price supplier

Disposable aluminum container plant CTJF-60T has been designed and developed as an upgraded model to produce aluminum food containers, dishes and trays. The working speed of this plant CTJF-60T is 50-75 pcs/min (with one cavity mould), and its speed depends on container as size and complexity. It can be equipped with multi-cavity moulds.

Disposable aluminum container plant CTJF-60T is composed of the followings:

1.

Decoiler (with an auto-lubricator)

2. Electrical control panel

3. Air output control equipment

4. 40 ton pneumatic press

5. Mould

6. Conveyor(including scrap collector)

7. Collection desk

??

Main Features:

(1) This plant can work automatically. Worker control and regulate this production line through electric control equipment.

(2) The width of decoiler is about 520mm .

(3) The feeding system control feeding length and stepping by computer, which assure a high-precision steps.

(4) We can design and manufacture different machines on request. There is some difference in machinea s outer-appearance.

(5) The press may be equipped with single cavity or multi-cavity moulds for wrinkle-wall or smooth-wall container production.

The working flow of plant CTJF-60T:

Aluminum foil roll ---decoiler---air output control equipment---60T pneumatic press---mould---conveyor--- collection desk---packing
