Automatic 5 gaLlon machine line
Automatic 5 gallon machine line
* washer/filler/capper 3 in 1
* stainless steel
* suit for 3 gallon-5 gallon
China automatic 5 gallon macine line
QGF Series barrel machine is specially used for 5 Gallon barrel drinking water. This machine integrates washing/filling/capping into one unit. It is the good ideals for produce the mineral water/distilled water/pure water equipments. Whole machine are adopt the high quality stainless steel, Strong for erosion proof ability, easy to washing. Mostly electric components are adopted SIEMENS, OMRON etc famous company. Electric component adopt import Air TAC famous brand product. The machine is advanced in construction, occupying small area, steady in performance, high in produce efficiency, high in automatization degree. Easy in operation, which integrates machinery, electricity and pneumatics technologies together into one unit full automatic barreling machine.
APPLICATION:
It is especially used for 5 Gallon barrel pure water washing, filling, capping production line.
CHARACTERISTICS:
The parts with touch water adopt high-quality stainless steel. The cylinder gear runs smoothly and the fixed position is correct. It adopts inserting-type washing technology to remove washing blind angle.
Product Description
1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine
Technical Specifications
| Model |
QGF-150 |
QGF-300 |
QGF-450 |
QGF-600 |
QGF-900 |
QGF-1200 |
| Filling heads |
1 |
2 |
3 |
4 |
6 |
8 |
| Barrel Size (mm) |
φ276*496 |
|||||
| Barrel Capability |
18. 9 l |
|||||
| Capacity (b/h) |
120 |
300 |
450 |
600 |
120 |
240 |
| Gas Pressure |
0. 4-0. 6Mpa |
|||||
| Gas Consumption |
0.6 |
0.9 |
1.8 |
2.5 |
0.6 |
0.8 |
| Power (KW) |
1.75 |
3.0 |
3.8 |
5.6 |
1.75 |
2.1 |
| Voltage |
380V/50HZ |
|||||
| Size (mm) |
3190x650x1550 |
3100x900x1650 |
3550x1100x1800 |
3800x1100x1800 |
3190x650x1550 |
3100x900x1650 |
| Weight (kg) |
800 |
1350 |
1860 |
2300 |
||
Zhangjiagang Longway Machinery Co., Ltd,is a hi-tech designing & manufacturing enterprise specialized in PET machinery and other kinds of plastic machinery in china. We offer clients from a single machine to a complete production line, our main products include:
automatic stretch blow molding machine
injection molding machine
PET bottle blow mold
3000-36000b/h mineral water & pure water processing and filling line;
3000-36000b/h fruit juice & iced tea hot processing and filling line;
100-2000b/h 5 gallons series bottling lines;
2000-36000b/h carbonated drink processing and cold filling line;
1000-8000b/h vinegar & wine filling and packing line;
Series of plant protein drink processing drink processing and filling lines;
Complete set of combined fruit & vegetable juice (or powder) producing line;
Various of water treatment equipment.
Also we provide turkey solution aiming at
