Automatic Carton Erecting & Sealing Machine (K8010109)

FOB Price:Price can be negotiated

Production Capacity:20 Sets/Month

Payment Terms: FOB, CIF, CFR, DDP

Update Time:2015-09-17

Contact Supplier

Product Description

Main Description
This machine which is composed of storage tank, PVC forming system, automatic feeding system, PTP sealing, date coding, cutting system, PLC controlling system & waste recycling, etc. is innovatively exploited for packing chocolate paste, peanut butter, sesame butter, cream, edible oil, washing detergent, cleaning solution, perfume, essence, drinking water & other liquids or paste materials.

Main Principle
PLC starting --Film baking --Film blistering --Film conveying --Materials filling --Laminating sealing --Final cutting

Main Parameter

Cutting rate	6-40batch /minute
Max packing specifications	360x 190x 26mm
Stroke range	40--200mm
Packing materials requirements	PVC Thickness/0.15mm--0.5mm ,Width /360mm
	PTP Thickness /0.15mm--0.5mm ,Width /360mm
	Dialysis Paper Thickness (50mm--100mm) ,Width /360mm
Overall power	6.2kw
Overall weight	2100kg
Overall dimension	4000x 600x1650mm
PS: All Specifications can be Customized.

Main Feature
1. Adopting PLC controlling system, stable working performance, Food Grade 304 SS making materials.
2. Utilizing servo motor driving, digital -intelligence, speed-adjustable, stroke & optional forming sizes.
3. With flat structure, mechanical positive pressure forming, pneumatic heat sealing.
4. Imported electric appliances, such as Omron, Siemens, Schneider, etc. ensure the stable working performance without defaults.
PS: To issue FORM A, FORM B, FORM E, FORM P, C/O, etc. for the privilege for local Custom Duty.
