Automatic Carton Packing Machine / Automatic Carton Packer,China SANOFI price supplier

Automatic L-bar Sealing & Shrink Packing Machinery

Technical data
BS-400LA
1) Sealing type: L-sealing by means of L-bar
2) Power supply: 380V/50-60Hz/3phase
3) Packing capacity: 35 packs per minute  (depends on product size and film width)
4) L-bar size: 570x480 mm
5) Max height of sealing frame: 125 mm
6) Film type: center-folded film with 12-80 micron
7) Max film size: width: 520mm (folded), outer diameter: 400mm
8) Conveyor speed: 19 m/min
9) Working height: 780-850 mm
10) Rated power consumption: 1.25 kW
11) Air pressure: ≤0.5MPa (5 bar)
12) Sealing system: permanently heated seal bar with easy-exchangeable sealing blade without odorous
13) Machine material: carbon steel and painted
14) Machine dimension: 1600x770x1450mm

Technical data
BMD-450C
1) Power supply: 380V/50-60Hz/3phase
2) Oven size: 1200(length) x 450(width) x 220(height) mm
3) Conveyor speed: variable, 40 m/min
4) Conveyor:  chains with rotating silicon coated rods
5) Temperature control: By electronic thermostat
6) Rated power consumption: max 7 kW
7) Working height: 780-850 mm
8) Machine material: carbon steel and painted
9) Machine dimension: 1600x600x1260mm
