Automatic cocoa powder printed plastic bags packing equipments,China KCX price supplier

Automatic cocoa powder printed plastic bags packing equipments

FOB Price:Price can be negotiated

Production Capacity:20 Set/Sets per Month 30

Payment Terms: US $8,320 - 10,680 / Set

Update Time:2014-09-20

Contact Supplier

Product Description

COCOA POWDER wrapping machines
1,25-60bags/min
2,High speed
3,PLC+Touch Screen
4,Different bag types

Automatic cocoa powder wrapping machine

turmeric powder, chilli powder, coriander powder, cumin powder, cocoa powder, etc.

1.Automatic Packaging Machine

Technical information

Model	KCX5000
Bag length	50-360mm
Bag width	80-200mm
Speed	25-60bags/min
Weighting range	50g-1000g
Accuracy	1%
Sealing form	Three sides
Air consumption	0.4cbm/min, 0.6Mpa
Body Material	Stainless Steel
Voltage	220V/50HZ/3Kw
Hopper capacity	60L
Film	PP/PE/POF
Parts
PLC _________OMROM, Touch Screen______TAIWAN Servo motor_______PANASONIC, Photo Sensor_____ Japan Air valve _________Korean

Technical Features:

1, Automatic photoelectric control, encoder control system

2, Gusset device and printing device

3, Automatic tracking code, bag-making, filling measuring, sealing, printing, product delivery in one operation.

2.CJSL2000 Auger Filler

This machine equips Sanyo Servo Motor, level switch and mixture motor automatic filling,

Controlled by packaging machine, Made by Stainless Steel .

3.DT1 SCREW ELEVATOR

1, Material: Stainless Steel

2, Automatic feeding.

3, Equips level switch and control box.

4.Production take-off conveyor

1, Material: Stainless Steel

2, Length: 1.95m

5.Air Compressor /one set.

Compressed air output: 0.6MPa, 0.4m ³ /min.

SAMPLE BAG:

Condition:	New	Application:	Powder	Packaging Type:	Bag
Packaging Material:	Plastic	Automatic Grade:	Automatic	Driven Type:	Electric
Power:	3KW	Place of Origin:	Shandong China (Mainland)	Brand Name:	KCX
Model Number:	KCX-5000	Film:	POF/OPP/PVC/BOPP	Certificate:	CE
Quality Grade:	A	Packing Speed:	25-60bags/min	Feature:	LCD display
Material:	stainless steel	Bag length:	50-360mm	Bag width:	80-200mm
Weighting range:	50g-1000g	Electric source:	220V	Type:	Packing Machine,Wrapping Machine
