Automatic filling sealing machine bar chocolate,China HOUSEN price supplier

Automatic filling sealing machine bar chocolate

FOB Price:Price can be negotiated

Production Capacity:60 Set/Sets per Month

Payment Terms: US $5,561 - 7,174 / Set

Update Time:2014-09-28

Contact Supplier

Product Description

Filling Machine bar chocolate
1.CE
2.Adjustable bag size and packing speed
3.35-180bags/min

Application Of filling machine bar chocolate

Suitable for packing pillow-type products such as tableware, medicine, chocolate, noodles,bread,egg rolls,ice cream, napkin and soap.

More Bag Style For You Referance

Feature

1.Terminal sealing device.
2.Separate PID control to temperature.
3.High inductive photoelectric eye tracking.
4.Positioned stop function without sticking knife or wasting film.
5.Simple driving system,reliable working,convenient maintenance.
6.All plastic pillow packing machine are controlled by software.
7.Interface features easy and quick setting and operation.
8.Self diagnosis of failure function,clear failure display.
9.Double frequency conversion control.
10.All control realized through software,easy for function adjusting and technical upgrade.

Parameter

Type	HSH-120	HSH-320	HSH-450
Film width	90-240mm	100-420mm	150-500mm
Packing length	65-160mm	80-200mm	100-300mm
Packing width	35-100mm	40-150mm	30-170mm
Packing height	5-35mm	5-50mm	5-80mm
Packing speed	35-180bags/min	35-180bags/min	35-150bags/min
Packing material	OPP/CPP,PT/PE,KOP/CPP,ALU-FOIL, etc
Dimension( mm )	(L)4000(W)920(H)1600	(L)4000(W)1020(H)1600	(L)4000(W)1020(H)1600
Total power	3.4kw(220v)	3.4kw(220v)	4.8kw(220v)
Overall weight	550kg	600kg	700kg

The Working Process

Automatic detection — automatic filling—automatic bagging—automatic sealing—automatic cutting—automatic counting.

Main Machine Parts

Optional

1. Date printer 2. Feeding device 3. Horizontal seal punching device 4. Nitrogen feeding device 5. Chute deoxidizer

1. Date printer

2. Feeding device

3. Horizontal seal punching device

4. Nitrogen feeding device

5. Chute deoxidizer

Free Spare Tool

Packing Process

Company Detail

More types machine, please click here!

Verified Information:

This information was Verified by TÜV Rheinland and is valid for the following period: 2013/01/28 --- 2014/01/28

The information below covers both the Gold Supplier and its related companies, which are defined according to china laws and regulations.

Production Capacity:

Product Line Name	Production Line Capacity	Actual Units Produced(Previous Year)
Packing Machine	40 Sets / Month	350 Sets

Export Market Distribution:

Market	Revenue(Previous Year)	Total Revenue (%)
North America	confidential	1.0
South America	confidential	10.0
Eastern Europe	confidential	15.0
Southeast Asia	confidential	5.0
Africa	confidential	10.0
Mid East	confidential	3.0
Central America	confidential	10.0
South Asia	confidential	10.0
Domestic Market	confidential	36.0

Testing Machinery:

Machine Name	Brand & Model No.	Quantity	Number of Year(s)Used	Condition
Vernier Caliper	Shanghai	3	3.0	Acceptable
Outside Micrometer	Guilin, 0.01mm	2	3.0	Acceptable
Micrometer Caliper	00000315	3	2.0	Acceptable

Production Flow:

Assembly	Performance Test	Packing

Assembly

Performance Test

Packing

Certification:

Certification Name	Certified By	Certificate No.	Product Name & Model No.	Available Date--Expired Date
CE	Ceprom Product Certification Body	175-CI-32012	Full-Automatic Packing Machine & HSH-120, HSH-320, HSH-450, HSH-600, HSH-2000, HSD-220D, HSD-420D, HSD-520D, HSD-620D, HSD-720D, HSD-220F, HSD-420F, HSD-520F, HSD-620F, HSD-720F, HSD-420S, HSD-220Z, HSU-160F, HSU-160K, HSU-160Y	2012/01/11 --- 2049/12/31

Certification Name

Certified By

Certificate No.

Product Name & Model No.

Available Date--Expired Date

Ceprom Product Certification Body

175-CI-32012

Full-Automatic Packing Machine & HSH-120, HSH-320, HSH-450, HSH-600, HSH-2000, HSD-220D, HSD-420D, HSD-520D, HSD-620D, HSD-720D, HSD-220F, HSD-420F, HSD-520F, HSD-620F, HSD-720F, HSD-420S, HSD-220Z, HSU-160F, HSU-160K, HSU-160Y

2012/01/11 --- 2049/12/31

Type:	Other,Packing Machine	Condition:	New	Application:	Paper
Packaging Type:	Bags,Film,Pouch	Packaging Material:	Plastic	Automatic Grade:	Automatic
Driven Type:	Electric	Voltage:	220V	Power:	3.4kw
Place of Origin:	Shanghai China (Mainland)	Brand Name:	HOUSEN	Model Number:	HSH-320
Certification:	CE	After-sales Service Provided:	Engineers available to service machinery overseas	Packing film width:	100-420mm
Packing length:	80-200mm	Packing width:	40-150mm	Packing height:	5-50mm
Packing speed:	35-180bags/min	Packing material:	OPP/CPP,PT/PE,KOP/CPP,ALU-FOIL, ETC	Dimension:	(L)4000(W)1020(H)1600mm
Total power:	3.4kw(220v)	Overall weight:	600kg

Company Profile

Name: Shanghai Housen Industry Co., Ltd.

Main Products: Packing Machine

Business Type: Manufacturer, Trading Company

Total Employees: 11 - 50 People

Established Year: 1997

Main Markets: Domestic Market, Eastern Europe, Africa, South Asia, South America

Address: No63,Lane7556 Hutai Road

Shanghai Housen Industry Co.,LTD as a professional manufacture and supplier specialized in developing ,producing and marketing packing machine all over the world.HOUSEN currently has marketing network involve distribution in more than 20 countries. And we enjoy a high reputation in South America, Europe, Africa and South East Asia.

Advanced equipment and standard production management ensure the quality of Housen products have the international standards.
Experienced R&D team and continuously product innovation are able to meet personalized demands from different customers.

You will no regret to choose us , not only price , machine quality , but also spare parts ,video for machine install and debug , after-service ,we have many strength ,because we are the extensively experienced factory , we are the source .

We will always show our sincere .Our task is to help you capture your client's heart or make your packing more individuation ,thus win the world market .

With the best quality, flexible service, and continuously innovation, Housen has been working to improve itself and continually creating values for partners. more
