Automatic Ice cream Cone Wafer Product Line 14 molds,China GELGOOG MACHINERY price supplier

Automatic Ice cream Cone Wafer Product Line 14 molds

FOB Price:Price can be negotiated

Production Capacity:100 sets

Payment Terms: 5000-150000usd

Update Time:2021-09-29

Contact Supplier

Product Description

Production:

The machine is fully automatic to make ice cream cone with high quality. Automatic wafer baking oven:Equipped with Touch-screen and programmed by Siemens . PLC Software ,this unit is of LPG to generate the heat energy to make ice cream cone Molded hollow wafer products such as cones or cups in various shapes with or without engraving are produced on fully automatic baking machine.The equipment is easy to operate which with automatic temperature control ,lighting to finish the baking process.the machine is made of stainless steel.and we can design the mold for your demand specially.we have sold the whole line to many countries.from our customer feedback,our machine can work well.

Advantages:

Adopting hearing-medium conduction technology with heating oil as medium,the plant is a new

generation product developed exclusively in China based on the advanced

structure of existing plants from domestic market and abroad.If offers an ideal

solution for lower power consumption and overall production cost,and keeping

the same surface color for all biscuits.The plant mainly consists of mixing system,

automatic feeding system, tunnel-type oven, sheet feeding and cooling device,coating machine,cutter and organic

Model	GGDL-14-1
Heating way	gas
Molds number	14sets
Dimension of the mold	350x100x325mm
thickness of the products	2.0－3.2mm
Baking time	95~150s(thickness of the products <3.2m)，the maxing temperature:180℃
Capacity	2000pieces/h (according to the size which showed in your picture, one mold just can produce 7 cones)
Material for the part contacting the food	Stainless steel
Mold material	Cast iron
Machine frame material	Carbon steel(paint spraying)
Thermal insulation material of the door	Aluminium silicate and rock wool
Feeding system	frequency conversion system
Feeding system dynamo power	0.75kw
Gas blower	2.2kw
Voltage	380V，50 Hz,3 phases
Power for the main dynamo	1.5kw
Total power	5kw
Gas consumption	14m3/h
Dimension of the machine	3270mm1560mm2320mm
Weight	5800kg
