Applications:
This is a semi-automatic packing machine specially manufactured for rationing, weighing and packing the flour that discharged forcefully by the feed screw gearing.
It’s also suitable for packing many kinds of powdery materials such as fish meal, maize meal and so on by doing some technical changes.
Flowing Process:
Manual Bag placing →Automatic filling →Automatic weighing →Automatic bag conveyer →Automatic bag sewing / sealing
Main Structures:
1. Automatic filling system 2.Automatic weighing balance
3. Automatic belt conveyor 4.Automatic sewing / sealing machine
5. Electric control cabinet
Technical Parameters :
Type : LCS-LX
Weighing Range: 25 ~ 50 (KG)
Output: 180-280bags/hour
Precision: ± 0.2%FS
Power : 2.2/3 (KW)
Electrical Power: 380/220 , 50(V/Hz)
Air Power: 0.4 ~ 0.6(Mpa)
Dimension: 1400×700×3100, 1310×700×2600 (mm)
M&J Machinery Introduction and application
M&J Machinery Engineer Co., Ltd. is one of the new leading packing resolution suppliers in China. Our main products is packing machine, bagging machine, powder packing machine, pellet packing machine, automatic packing palletizing plant, mortar mixing plant, fish meal producing plant. It has authorized permit enterprise from the state and Jiangsu technical supervision department. And also the independent import/export license. M&J design, produce and install from the single quantitative bagging machine, to completed automatic bagging systems, and other large bagging projects. Appeared many industries, throughout domestic and foreign countries, and was widely recognized. In 2006, M&J obtained ISO9001-2008 certification. In the same year, it was awarded with the title of Quality Confirmed Firm by the Committee of the Jiangsu Reputation and Quality Supervision.
M&J managers deeply understand talents are the most precious resource in 21st century, and it is important for keeping development and competitive advantages. M&J always insists developing human closely together with products, aborting and respecting talents, continue to improve the operation mode, set up the unique talent strategy, providing soil for excellent talents .Now our development team has more than 10 professional engineers, takeing fine powder, chemical raw materials, naphthalene and other special materials as our key research and development direction, have achieved some breakthrough.
