Automatic PET bottle blow molding machine, 4 cavities,China price supplier

Automatic PET bottle blow molding machine, 4 cavities

FOB Price:Price can be negotiated

Update Time:2013-10-17

Product Description

CM-A4 Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.

Product Feature
1.)Reasonable design, full automatic control, save power and labor. Adopt high quality components,
2.)Feeding system carries the performs by robot automatically.
3.)Infrared oven heater adopts the quartz lamp to heat the PET preforms.
4.)Fully automatic process with low investment, high efficiency ,quick and safe operation ,easy for trouble -shooting , maintenance and other benefits.
5.)We have perfect service after sales .

Productivity ( Depend on bottle design): 3200 to 4000pcs/h
Mould: 4cavity Bottle Body diamerter: 20mm to 100mm
Bottle height: 50mm to 350mm
Bottle neck diamete: 15mm to 32mm
Mould thick: 240mm
Mould: 500X500mm
Electrical source power: 380v 3Phase 220v 2Phase 50/60HZ
Power: 48kw Really use power: 14kw Operation air: 2000NL(8.0bar)/min B
low air: 2500NL(3.0bar) min Cooling water: 150L
min Size ( LxWxH): 1908x1858x1920mm
Weight: 3600kg
Auxiliary equipment : Preform unscrambler is equipped as standard

Other Products

PET bottle blow molding machine, semi-automatic

Automatic PET bottle blow molding machine, 4 cavities

Automatic PET bottle blow molding machine, 2 cavities

Company Profile

Name: KINGTOP INTERNATIONAL GROUP LTD

Main Products: bottle blowing machine, blow molding machine, mould, bottling line, preform, plastic packing

Business Type: Manufacture

Address: International Trade Rd

Dear Sirs,
We supply following PET bottle blow moulding machine to make mineral water bottle, shampoo bottle, washing bottle, edible oil bottle, wine bottle, pharmacy container, milk bottle and other daily usage bottles and containers from 50ml to 20L with different shape and neck diameter:
I.) Semi-automatic blow molding machines:
1.) CM-9A stretch blow molding machine for PET bottle from 0.1L to 5L
2.) CM-9B stretch blow molding machine for PET bottle from 5L to 10L
3.) KINTL-5G stretch blow molding machine for PET bottle up to 5 Gallon

II.) Automatic blow molding machines:
1.) CM-A1 automatic blow molding machine with single cavity moulds for PET bottle up to 5L
2.) CM-A2 automatic blow molding machine with 2 cavities moulds for PET bottle up to 2L
3.) CM-A4 automatic blow molding machine with 4 cavities moulds for PET bottle up to 2L

We also supply following products:
1.) Various moulds for preforms and bottles
2.) bottling lines
3.) preforms and caps
4.) injection molding machine to make preforms and caps more
