Automatic Shrink wrapping machine,China SANOFI price supplier

Automatic packaging shrink machinery / equipment

1.CE certificate
2, Capacity: 2-5b/m
Wrapping dfferent case and bottle

Automatic packaging shrink machinery / equipment

One.Technical parameters

·Equipment type: WD-150A

·Outline dimension of the equipment:L5050*W3300*H2100mm

·The largest dimension of the wrappage:L600*W400*H350mm

·Material of shrink film:PE

·Thickness of shrink film:0.03-0.15mm

·The highest temperature of the heat shrink furnace: 160-260 ^.

Can adjust freewill.

·The maximum production per minute:0-12 pakage

·Equipment capacity: 20Kw

·Actual power consumption:15Kw/hour

·Pressure request:220V

·Equipment weight:1.2T

·Machine reuired air pressure of the compressor:0.6-0.8Mpa

Technical requirement and request:

1.      Packing terms:

(1)350/500/550/600ML large package: 4*6, 4*5

                     Small package: 3*4, 3*5

 Four packing terms.

(2)1L/1.5L/2L/2.5L   large package:3*3,3*4

                   Small Package:2*2,2*3

Four packing terms.

2.      For the pop can packing ,we advise packing with pallet,it will be steady.

3.      Packing speed:8-15 bundles/minute

4.      Satisfy the speed of the liquid filling machine.

(1)350/500/550/600ML large package :4*6, 4*5, (12000-15000 bottles/hour)

Small package:2*3,2*2(3000-4000bottles/hour).

5.      Material of packing:the wideth of PE heat shrink film (200-600mm),thickness(0.08-0.12mm)
