Automatic sparking mineral water production line ,sparkingwater filler,China longway price supplier

Automatic sparking mineral water production line ,sparkingwater filler

FOB Price:Price can be negotiated

Update Time:2021-10-19

Contact Supplier

Product Description

Automatic sparking Mineral Water filler ---Product Description

(1) All parts of the filling machine touch with the material adopt high quality stainless still. Through the polishing treatment the surface become easy to clean. Sealed material is rubber or EPDM material.

(2) Using programmle controller as the central control,using pressure transmitter, electromagnetic chaos pneumatic servo measurement level to maintian the balance of filling pressure in order to ensure the stability of the liquid surface.

(3) Designed new filling valve for plastic bottle, return-air and filling tank liquid are separation to ensure the cleaning of filling materials.

(4) The filling machine adopts advanced magnetic clutch-type screw cover head, torque is adjustable. Screwing cap is safe and reliable.

Automatic sparking mineral water filler ---Product Main Technical Data

Model(DCGF)	12-12-5	18-18-6	24-24-8	32-32-8	40-40-10	50-50-12	60-60-15	80-80-20
Number of washing,filling,capping heads	12-12-5	18-18-6	24-24-8	32-32-8	40-40-10	50-50-12	60-60-15	80-80-20
Suited bottle specification (mm)	Φ=50-100 H=170 330-1500ML			Φ50-Φ110 H=160-340
Production capacity(350ML) b/h	2000- 4000	4000- 6000	8000- 10000	10000-12500	12500 -15000	16000 -20000	20000 -24000	26000 -32000
Washing pressure (MPa)	0.2-0.25			0.2-0.25
Filling pressure (MPa)	0.15-0.35	0.15-0.35	0.15-0.35	0.2-0.4	0.2-0.4	0.2-0.4	0.2-0.4	0.2-0.4
Motor power	1.5+0.55 +0.12	2.2+0.55 +0.18	3+0.55 +0.18	5.5+0.55 +0.18	7.5	11	15	19
Overall dimensions (L×W×H) mm	2300×1600 ×2500	2600×1920 ×2550	3100×2200 ×2800	3850×3000 ×2850	4850×3800 ×2750	5750×3550 ×2750	6500×5500 ×2750	7680×6640 ×2650
Weight kg	2800	3650	4800	6800	8650	10500	12800

Automatic sparking mineral water filler --Welcome to our factory!
