Automatic stretch blow molding machine

FOB Price:Price can be negotiated

Update Time:2011-07-22

Product Description

Automatic stretch blow molding machine can produce bottles from 5L to 25L.
Patent feeding system carries the preforms automatically.
Rational design of Oven heater is to ensure extremely even heating for the preforms.
High capacity for producing 5 gallon PET bottles.

Information:

Ceneral Information	CP-PET-120
Clamping Force	34T
Clamping Stroke	330mm
Max.Stretching Stroke	550mm
Bottom Moving Stroke	70mm
Number of Cavities	1Cavity
Theoretical Output	120BPH
Max Mould Thickness	400mm
Space Between Tie Bars	520x600mm
Electrical System
Voltage Standard	380V/3PH/50HZ or special order
Number of Heating Zone	2Sections
Total Power(Full Loaded)	15KW
Container
Max.Container Volume	25L
Neck Diameter Range	65mm
Max Container Diameter	400mm
Max Containef Height	550mm
Auxiliary System
Low Air compressor	8-10Bar
High Air compressor	30Bar
Air Dryer	2.0/30
Dimension & Weight (LWH)
Blow molding machine	260x190x195cm
Preform Oven	-
Net Weight	5.2Ton
