Technical Specifications
Model : MPAPF-2
Output/Minute* : 2400 to 3600 (UP to 25 gms Filling Size)
1200 to 2400 (Above 25 gms Filling Size)
Direction of Movement : Left to Right
Number of Filling Head : 2 Head
Electric Specification **
Main Motor (Stirrer) : 0.5 HP / 415 Volts 50 Hz. – 2 Nos.
Conveyor Motor : 0.5 HP / 415 Volts 50 Hz.
Servo Motor : 750 Watt – 2 Nos.
Air Consumption : 4 – 6 Kg. Pressure
Height of Conveyor** : 860 mm ( + 50 mm adjustable height)
Machine Dimensions** : 1830mm (L) X 700mm (W) X 1800mm (H) approx
Case Dimensions** : 2100mm (L) X 900mm (W) X 2400mm (H) approx
Net Weight : 500 Kg.
Approx Gross Weight : 850 Kg. Approx
Salient Features
· ± 2 % Filling accuracy on single dose.
· All Contact Parts in SS 316
· Adjustable height of Conveyor Belt.
· Low Noise Level, Low Power Consumptions
Utility Requirement
Electrical supply : 3 Phase + Neutral + Earthing
Electrical load : 1.8 KW
Air Pressure : Minimum 4 to 6 bar pressure.
Powder Filling Machine has improved its immense industry steadily. Our encyclopedic products efficiently function the pharmaceutical industry. We invent a entertainer of pharmaceutical machinery like powder filling machines, powder filling machines, Automatic Single Head Augur Type Dry Syrup Powder Filling Machine, Automatic Two Head Augur Type Dry Syrup Powder Filling Machine, Automatic Three Head Augur Type Dry Syrup Powder Filling Machine, Semi Automatic Augur Type Dry Syrup Powder Filling Machine, Bottle Washing Machine, Liquid Filling Machine, capping machines, tube filling machines, Labelling Machine.
We invent our encompassing fluid communication using tiptop magnitude raw materials according to the requirements of the machine. The raw matter is procured from certified vendors and proved at our unit before finally utilizing them to make our pharmaceutical machinery.
Quality:
We insure cosmopolitan grade discipline measures at every coach of system & production of our products. We state the latest machinery for conducting exhaustive physiologic tests of our products ensuring that they execute to the maximal standards of level & precision. Our unit of experts maintains an exact rite and runs symmetric checks on the level of products that are manufactured before they are dispatched to our customers.
Infrastructure:
We have a unit of industry experts, engineers and technocrats who have vast business receive. Their in-depth knowledge of the business has assumption us and render above our competitors. We deal lawful activity sessions at our thing to livelihood our manpower abreast with the changes attractive area around the mankind in the pharmaceutical machinery.
Our interracial search and process group is continuously engaged in innovating newer concepts to update our existing products and also conceptualize new products. Our search artefact is accoutered with current research tools and equipment that insure true results. Our group of researchers handle marketplace surveys to understand and ready a tap on the dynamical industry trends.
