 Automatic Bag-Given Doy pack Machine Stand Up Bag Packaging Machine

 Applications:
The bag given weighing filling packaging system is suitable for the automatic weighing and package of  refined monosodium glutamate, coffee beans, nuts, almonds,  seeds, sugar, chicken essence, fried food, gum, pistachios, melon seeds, pet food, snack food, etc.

Functions and features:

The whole system include

---Z shape bucket elevator

---10 head combination weigher

---rotary bag given packing machine

---output Conveyor belt

Working procedures:
Station 1         Bag feeding

                Feed many pouches or bags in the bag magazine, our main bag magazine can move up and down, you can feed bags very easily when it moved down, and when it moved up, there are a mechanical arm with two vacuum caps will take bag up and then transmit it to the mechanical gripper on the rotary table.

Station 2         Date Printing (option)

Station 3         Opening

                To open stand (flat) pouches from top and bottom with two sets vacuum caps.

Station 4          Filling

Measured its weight or volume by scales.

                 There are an opening detection device insert into the open bag or pouch to expanding it and detect if it is open or not.

                 No open no filling no sealing

Station 5         Sealing

                 To seal the pouch or bag mouth with a couple of heat sealing air bar, the sealing pattern you can option, net or straight lines

Station 6         Forming and output

                To make the sealing stable and preventing from wrinkling with a couple of cold press, then output the finished production automatically.

Specifications:
1) Scaling scope: 5 - 1,500g
2) The styles of packaging bag: portable bags, hand luggage, zipper bags, 4-side
edging bags, 3-side edging bags, paper bags.
3) Speed: 60packs/min (max.)
4) Size of bag: W:200-300mm L:200-450mm/ W:150-260mm L:150-350mm/ W:100-210mm L:100-350mm

5) Total power: 3.5kW, 220/380V,50-60Hz
6) Weight accuracy: 1g

7) Air source: 0.6m3/min
