beverage filling capping 3-in-1 machine,China Gongda Machine price supplier

beverage filling capping 3-in-1 machine

FOB Price:Price can be negotiated

Payment Terms: T/T

Update Time:2014-07-09

Contact Supplier

Product Description

pecifications

Pure water filling line
Bottle washing, filling and capping of pure water, mineral water, FRUIT JUICE and liquor, etc.

1. Principal feature

This machine combines the bottle washing, filling, capping functions on one machine. It can be used for different kinds of fruit juices, tea, and hot drink packing. With several parts changed, the machine can also be used for mineral water filling. The design of the machine is scientific and reasonable .The appearance is beautiful and the function is complete. Its operation and maintenance is convenient. The filling and capping will be stopped automatically when there is no bottle. The filling is quick, steady and accurate. The Beverage feedback system is well designed; the gas can be fed back separately, no contacting the beverage to reduce the second time polluting and oxidation.

2. Principal parameter

Mode	GD16-12-6	GD18-18-6	GD24-24-8	GD32-32-10	GD40-40-12	GD50-50-15
Production capacity (600ml)(b/h)	3000	6000	10000	14000	18000	24000
Way of filling	Gravity filling technology
Filling precision	(Distance from liquid level to bottle mouth)≤5mm
Feedback consumption	≤8%
Specification of polyester bottle	(Bottle diameter)50-92mm; (Bottle height):150-310mm
Suitable cap shape	Plastic screw cap
Water pressure of washing bottle (Mpa)	0.2-0.25
Water consumption for water bottle (Kg/h)	800	1600	2500	3500	3500	4500
Pressure of gas source (Mpa)	0.6
Gas consumption (m3/min)	/	0.3	0.4	0.5	0.55	0.6
Total power (KW)	5.88	6.68	7.68	9.18	10.18	11.8
Total weight (Kg)	2500	3500	5500	8000	10000	12000
Overall (mm)	230015502500	251620162700	300022002800	415026002900	455027502900	545033002900
