Beverage mixing machine,China GD price supplier

Beverage mixing machine

FOB Price:Price can be negotiated

Production Capacity:10 SETS PER MONTH

Update Time:2021-06-28

Contact Supplier

Product Description

beverage mixing machine is used for carbonation and proportion mixing of water, syrup, and CO2, in producing carbonated beverages, for examples, lemon, coca cola, fruit’s Juice and so on. It is the main equipment in whole beverage production line. (Especially for middle and higher standard beverage production).

Characteristics:

1) This machine adopts advanced technology from chemical industry– Static Mixing device (also named carbonization device). The contact surface of gas and liquid is full and the resistance is low, thus featuring high efficiency and low power consumption. Its structure is also concise and employing reliable multi-grade carbonation pump which is quiet and controlled by frequency convertor for start or run, thus ensuring the good performance of the complete equipment.

2) Precise mixing proportion and adjustable: To adjust the capacity or mixing proportion, no need to change any parts.

3) This machine adopts CO2 reflux for deoxidation, featuring economic use of CO2 and good effect of deoxidation.

4) This machine can conveniently adjust volume of carbonation in terms of the requirements of beverage’s carbonation. It can be done through suitable operation and adjustment to complete the procedure.

5) This machine has full automatic controlling system; it has advantages of concise structure, harmonious working action, continuous production, and high automatic performance.

6) This machine has cleaning procedure in original position and favorable structure. Convenient chemical disinfection or heating disinfection or cleaning with clean water can be carried out according to hygiene requirements of foods.

2Main Technical Parameters

(1). Capacity 5000kg/h

(2). Range of proportion (syrup to water) 1:3 – 1:10

(3). Volume of Carbonation (CO2: H2O in volume) 〉2: 5

(4). Mixing precision tolerance ≤2%

(5). Cooling water temperature inlet 0-4℃

(6). Cooling water pressure inlet 0.01-0.08MPa

(7). Syrup temperature inlet 2-8℃

(8). Syrup pressure inlet 0.01-0.08MPa

(9). CO ₂ pressure inlet 0.7-0.8MPa

(10). CO ₂ purity ＞99.9%

(11). Pressure for pre-carbonation tank and syrup tank 0.05-0.09MPa

(12). Pressure of the finished tank 0.2-0.5MPa

(13). Total motor power 8.55kw

(14). Overall dimension (long * wide *high) 2200*2200*2400mm

(15). Total weight 1600kg
