CE certificate automatic Oats corn flakes machine,China Liaohai price supplier

CE certificate automatic Oats corn flakes machine

FOB Price:Price can be negotiated

Production Capacity:10 Set/Sets per Month

Payment Terms: US $50,000 - 200,000 / Set

Update Time:2022-07-15

Contact Supplier

Product Description

1.Output:3-5T/H
2.High wear-resistant alloy Roller
3.PLC automatic control
4.high quality

Detail

Performance characteristics

Through years of accumulated experience in the practice of rolling billet,combined the processing technology of the oatmeal and the difference in characteristics with the characteristics of the oats, our Company produces the press machine with the following characteristics:

1.After quenching and tempering,the oats roll into tight by hydraulic pressure.With relative pressure,a uniform piece comes out from between two rollers.

2.High yield,up to 3T-5T/h.

3.High-intensity square bearings,high wear-resistant alloy roller.

4.High degree of automation,use of PLC automatic control.No need to adjust manually.

5.Intermittent control flaking pump station.

6.All stainless steel components.

7.Auto flip magnetic body.

8.Built-in sealing material mountain shoulder,external manual adjustment.

9.The entire machine's electrical equipment,hydraulic parts,bearing accessories,are imported and practically do not need maintenance.

Model	Dimesion(mm)	Power(kw)	Roll Diameter(mm)	Roll Length(mm)	Tablet Thickness(mm)	Capacity (T/D)
GCYYMYP6001000	190016351600	18.5*2	600	1000	0.25-0.4	50
GCYYMYP600800	170016351600	15*2	600	800	0.25-0.4	40
GCYYMYP600500	90016351600	7.5*2	600	500	0.25-0.4	15

Project References

Engineering Achivement

700TPD----Hebei Yufeng Group

500TPD----Hubei Fukang Oil Co., Ltd

1000TPD----Shandong Dacheng Oil Co., Ltd

1500TPD----COFCO (HubeiJinzhou)

1500TPD----COFCO (HubeiHuanggang)

6000TPD----Jiusan Oil&Grains Industries Group Co., Ltd (Dalian)

Gallary(main equipment)

Detail 1

Detail 2

Detail 3

Detail 4

Detail 5

Introduction

1.Assimilating advanced technology optimize design
2.Adopting square bearing base and frame con struction to keep more stable
3.hydraulic baffle exists in the two rollers
4.Stable and reliable high-tensile frame
5.Two stage automatic turning magnetic separator
6.Roller gap adjustable
7.High quality bearing and thin oil lubrication
8.External scraper made by heavy cast iron, baffle device adjustable

Services

1. Choice of device models.

2. Designing and manufacturing products in accordance with the special requirements of customers,

3. One-year limited warranty of the vulnerable parts

4.Late services: telephone & mail & video

International trade

We are the first oil equipment manufacturer who gethered the traditional manufacturer and international trade in Alibaba.

We do business in vegetable oil, food industry, feed industry and chemical industry.

Tracy zhang

Tel: +86-28-87424353

Condition:	New	Type:	Other	Place of Origin:	China (Mainland)
Brand Name:	Liaohai	Model Number:	600*600	Voltage:	380V
Power(W):	17 Kw	Dimension(LWH):	90016351600	Weight:	1.8T
Hot searching:	Flaking Machine"> oat flaking machine	Thickness:	0.25-0.4mm	Output:	3-5T/H
RPM:	280r/min	Guaratee:	2 years and maintenance for long
