blast freezer
air defrost system
frozen time: 30~60min, +35/-40C
for various vegetable , fruits, meat, Pasta
LSZ series IQF Quick Freezer Machine Blast Freezer
Cherry Freezing Machine IQF Quick Freezer Blast Freezer" ori-width="800" ori-height="78" />
cherry IQF quick freezer machine Working principle:
The best equipment for quick freezing all kinds of fruit&vegetable and some of the seafood.
Adopts the two stage belting structure---fristly, quick-cooling step. Secondly, deep-freezing step. Independently speed control system, and the speed of the two meshbelts can be changed infinitely.
1.Quick-cooling stage--- the food particles are to be quick cooled after entering into the blast room. The surface of the particles would frozen and reach the temperature of 0 C. meanwhile, with the help of the striking chain, the particles would neither stick together nor sticke on the stainless steel meshbelt.
2.Deep-freezing stage--- the food is to be moved on a stainless steel meshbelt, the foodstuff layer loosens with the increasing of the airflow. Some of the foodstuff particles become floating(this is the reason why this equipment is not applicable to big bulk foodstuff) when the air pressure reaches a certain scale, which brings interspace among the foodstuff particles, that is the way the fluidized bed come into being..
Main Technical parameter for the cherry IQF quick freezer machine ,
| Model |
Dimension (m) |
Capacity (kg/h) |
Input temp. ( °C ) |
Output temp. ( °C ) |
Freezing temp. ( °C ) |
Freezing time (min) |
Coolant |
Cold load consumption(kw) |
Power required(kw) |
| LSZ-0.5 |
7.2*3.8*3.78 |
500 |
+15 |
-18 |
-36+/-2 |
5~50 continually adjustable |
R717/R22/R404A |
115 |
28.1 |
| LSZ-1.0 |
8.2*4.4*3.78 |
1000 |
186 |
40.1 |
|||||
| LSZ-1.5 |
10.2*4.4*3.78 |
1500 |
256 |
51.5 |
|||||
| LSZ-2.0 |
11.2*4.4*3.78 |
2000 |
325 |
64.7 |
|||||
| LSZ-2.5 |
12.7*4.4*3.78 |
2500 |
415 |
66.2 |
|||||
| LSZ-3.0 |
15.2*4.4*3.78 |
3000 |
520 |
90.5 |
|||||
| LSZ-4.0 |
17.2*4.4*3.78 |
4000 |
615 |
104.5 |
|||||
| LSZ-5.0 |
20.2*4.4*3.78 |
5000 |
800 |
128 |
Zhejiang Sanshon Machinery Manufacturing Co., Ltd was founded in 1993, located in the most convenient transportation and prosperous economy of Yangtze River delta Shangyu city, Zhejiang. Zhejiang Sanshon Machinery Manufacturing Co., Ltd adjacent to the beauty of the CaoE river, and in less than 5 KM there are three expressways, they are Hangzhou-Ningbo (G92), Changshu-Taizhou (G15w), and 104 national road line , the HangYong high speed railway. Moreover it is less than 100 KM to Hangzhou and Ningbo airport.
It is specialized in manufacturing food processing machinery, which includes fruit & vegetable hot air drying(AD), quick freezing (IQF), vacuum freeze dryer(FD). The company passed ISO9001:2000 quality standard under the efforts of all employees. There are three equipments has been assessed as National New Product. And in 2007, Sanshon was recognized for New and High Technical enterprise in Zhejiang Province.
The company not only in r&d and manufacturing ,but also enjoy the right of import and export. And the machinery from Sanshon has been exported to more than 10 countries, including Vietnam, Thailand, Uzbekistan, Azerbaijan, Iran, Mexico, Venezuela, Peru, Australia, Cyprus, Libya, etc.
Based on more than 20 years’ experience in food process machinery manufacturing, later it established Shaoxing Sanshon Steel Co., Ltd (www.cnsxgg.com) and Shundi foods Co., Ltd(www.shundifoods.com)in Zhejiang and Shanghai. Sanshon now is capable of providing integrated services, including product consultation, design, workshop establishment, equipment manufacturing and installation, training of machine operation in the field of vacuum freeze drying machine (FD), hot air drying (AD) as well as quick frozen (IQF) machines.
Sanshon is well prepared to be a pioneer in the field of dehydration, quick frozen, vacuum freeze drying to contribute to food processing industry!
Term,Conditions
Ordering Information
Payment:
we usually accept T/T,L/C, please send email to negotiate payment term if you can not accept T/T or L/C.
Packing:
iron framework with external plywood and seaworthy package
Please send email for the extra cost of different packing
Delivery Time:
different products will spend different production period: from 30-120 days after 50% advanced payment.
For urgent order, Could be faster, please send email to negotiate
How to make an order?
1,Client make 50% deposit or open LC after receiving our PI
2,Client approve our equipment,
arrange shipment
1,Client effect balance payment before shipment
2. supplier send original documents or telex release the goods
3,quality warranty for 1 year after shipment
| Condition: |
New
|
Place of Origin: |
Zhejiang China (Mainland)
|
Brand Name: |
Sanshon
|
| Model Number: |
LSZ
|
Type: |
Freezer
|
Voltage: |
380V/3P/50HZ
|
| Power(W): |
28.1kw
|
Weight: |
10T
|
Dimension(L*W*H): |
7200X3800X3800mm
|
| Certification: |
ISO,CE,UL
|
Warranty: |
1 Year
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
| Material of machine: |
SUS(AISI)304
|
Application of machine: |
blast freezer
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
