Chocolate nuts bar processing line

FOB Price:Price can be negotiated

Production Capacity:99 Set/Sets per Month

Payment Terms: US $200,000 - 600,000 / Set

Update Time:2014-09-28

Contact Supplier

Product Description

has all automatic continue techndogy,high production advanced technology.Coordinate with the Chocolate spray machine

Compound chocolate bar line automatic shaping machine ( 3.5-4T/8H )

A.Compound chocolate bar line automatic shaping machine is all kinds sugar line produce eguipment.It has all automatic continue techndogy,high production advanced technology.Coordinate with the chocolate spray machine,it can produce all kinds chocolate compun products.

B. parameter

NO	Name	Size
01	Dissolving sugar cooker	ø 1500×1300
02	Sugar storage tank	ø1000×1400
03	Nuts/sugar syrup Mixer	1425×500×614
0 4	Compound single roller	1200×1000×1400
0 5	Compound group roller	1200×1000×2450
0 6	Refrigerator inside group roller	1300×1300×200
0 7	Dust spray machine	3500×1000×1100
0 8	17M Coolin g Tunnel	17000×1000×1300
09	longitudinal cutter / longitudinal shunt Conveyor	3300×1100×1100
1 0	T ransverse cutter	1800×1000×1800
11	180° Swerve machine	3000×5000×1100
12	Sugar grinding machine	1240×960×1733
13	Oil dissolving tank	1900×650×1000
14	Chocolate milling machine	2700×1250×1800
15	Chocolate thermal cylinder	ø 1220×1850
1 6	Chocolate Enrobing Machine	14000×1140×1800

1. Dissolving sugar cooker

This product has the feature of melting sugar,good insulation , simple/easy operation, convenient maintenance, low failure rate and long service life, It is an indispensable equipment in the candy production line

Volume:500L

Outside dimensions: ø1000*1400 mm

Heating area: 2 m²

Working pressure:0.09Mpa

Working temp:120°C

Power:1.1kw

2. Sugar storage tank

Converying the dissolving syrup to the storage tank and keep the temperaturer at 100°C for preparation of the depositing.

Volume:500L

Outside dimensions: ø1000*1400 mm

Tank diameter: ø900 mm

Weight:200kg

Power:0.75kw

3. Nuts/sugar syrup Mixer

Used for Mixing Nuts and syrup

Outside dimensions: 1425 × 500 × 614 mm

Weight:100kg

Power:21kw

4. Compound single roller

Pressing the mixture of nuts,grain and syrup

Outside dimensions: 1200×1000×1400 mm

Weight:1000kg

Power:4kw

5. Compound group roller

Spraying one layer of caramel syrup on the nuts candy bar

Outside dimensions: 1200×1000×2450 mm

Weight:1500kg

Power:5kw

6. Dust spray machine

Praying granule nuts on the candy bars, then pressing by the rollers

Outside dimensions: 3500 × 1000 × 1100 mm

Weight:300kg

Power:2.2kw

7. 17M Coolin Tunnel

Cooling the pressed sugar bar for eariler cutting

Outside dimensions: 17000 × 1000 × 1300mm

Weight:800kg

Power:12.5kw

8. longitudinal cutter/ longitudinal shunt conveyor

longitudinal cuting the candy

Outside dimensions: 3300 × 1100 × 1100mm

Weight:1000kg

Power:5.2kw

9. T ransverse cutter

Conveying the longitudinal cut candy to the transverse cutter for cutting

Outside dimensions: 1800 × 1000 × 1800mm

Weight:500kg

Power:1.5kw

10. 180° Swerve machine

Conveying the cut candy bars to chocolate enrobing machine for chocolate coating

Outside dimensions: 3000 × 5000 × 1100mm

Weight:300kg

Power:3kw

11. Sugar grinding machine

It is used in the secondary grinding of sugar of flour. The average garin size is 100 mesh.

Spindle motor power:7.5kw

Feeder motor power:1.5kw

Spiudle speed:3800r/min

Weight:500kg

Outside dimension: 1240 × 960 × 1733mm

12. Oil dissolving tank

This equipment is the main part in the chocolate production line, it is mainly used for melting the chocolate syrup.

Water temperature in the jacket: 40-65 °C

Nominal capacity: 120 × 3kg

Outside dimension: 1900 × 650 × 1000mm

Weight:180kgs

13. Chocolate milling machine

The machine is a key equipment in the chocolate production line, it is mainly used for fine grinding of chocolate paste material and it also can be use for grinding of bean power oil liquid material and daily application chemical materials.

Max capcaity:1000L

Fine grinding grain: 20-25µm

Fine grinding time: 14~20h

Power:22kw

Weight:4100kg

Outside dimension: 2700 × 1250 × 1800mm

14. Chocolate thermal cylinder

The cylinder with adoption of rated temperature(temperature adjustable) for retaining of fine ground chocolate paste material viaagitating makes chocolate the degassing,de smelling,dehydrating and preventing the paste form the separation of oil and grease etc.functions.

Max capcaity:1000L

Power:2.2kw

Outside Dimension: ø 1220*1850 mm

Weight:1000kg

15. Chocolate Enrobing Machine

This chocolate enrobing machine is a special plant which can be used for enrobing candy,pastry,cookie,biscuits etc.

Speed of belt:0-8m/min(Stepless speed change)

Width of belt:750mm

Width of conveyor belt:820mm

Speed of conveyor belt:0-8m/min(Stepless speed change)

Total Power:15kw

Size:14000*1140*1800mm

Weight:3000kg
