cocoa powder packing machine for open mouth bag,China PUDA price supplier

Automatic powder Filling Machine for open mouth bag

It is designed for packaging a wide range of dry powders,flaked materials. The concept is that the screw/auger feeder conveys the materials to the sack. The superior design of the drive system permits high-speed bulk filling and extremely low-speed trim feeding,therefore ensuring accuracy without sacrificing the bagging rate.

Applications of screw packaging machinery:
Food: Starch, Baking powder, Flour Mixes, Cake mixes, Milk Powder, Yeast,  Ingredients, Tea, Sugar, Salt, etc.
Feed: Supplements, Alfalfa Meal, Fish Meal, Blood Meal, etc.
Chemicals: Carbon black , Fertilizers, Pigments, Resins, Heavy calcium carbonate, Gypsum, Titanium dioxide, etc.
Minerals: Cement, Clay, Mica, Lime, Stucco, Tile grout, etc.

Specification

1. Packing speed:1~3bags/min
2. Accuracy:±0.4%~0.6%
3 Weighing range: 5~10kg 10~25kg 25~50kg
4. Air pressure: 0. 5~0.7Mpa
5. Power supply: 380V 50Hz
6. Power:5KW

Main configuration

  Features and benefits

1.High quality components that meet the requirements of heavy industry.

2.Consistent and high fill accuracy.

3.Easy to use operator interface with PLC.

4.Advanced dust cleaning technology which promotes cleanliness of the equipment during operation.

5.Low dust emission

6.Easy to clean

7.Adjustable sack support saddle for different sack sizes

8.Fully automation available with options of peripheral equipments

9.Various products are accommodated by a multi-configuration of material inlets and bottom transition hoppers
