Cocoa Powder Vibrating Screen,China Zhenying price supplier

Cocoa Powder Vibrating Screen

FOB Price:Price can be negotiated

Production Capacity:300 Set/Sets per Month

Payment Terms: US $1,000 - 8,000 / Set

Update Time:2014-09-20

Contact Supplier

Product Description

1.Strong vibrating force gives the most effective powder screening;
2.Continuous powder flow eliminates oversize particles;

COCOA POWDER Vibrating Screen" ori-width="800" ori-height="518" />

Cocoa Powder Vibrating Screen

Cocoa Powder Vibrating Screen is a specially modified version of the internationally popular “Laosoung

Separator”. Its stainless steel perforated plate screen deck has been specially designed to provide

‘safe areas’ for product loading and reject discharge. The special pellet deck works in complete

harmony with gentle vibration and guarantees total removal of ‘longs’ from the fine powder. A

second lower deck can be fitted if required, utilising a woven wire mesh for the removal of dust

and fines.
------------------------------------------------------------------

CONSTRUCTION FEATURES

1.Clamping system by copper screws
2.All parts in contact with the product are made of SUS304 stainless steel
3.Base made of Galvanized carbon steel
4.Discharge outlet with sloped bottom
5.Electrical vibrator, IP 55 insulation
------------------------------------------------------------------

Application Range:
at powder lines,mill discharge or storage tank discharge for separation, purification,grading,refining,dedusting,filtration.
------------------------------------------------------------------
Applicable materials:

Chemical industry: resin, pigment, industrial medicine, cosmetic, coatings, Chinese medicine

power.
------------------------------------------------------------------
Food industry: sugar powder, starch, salt, rice noodles, milk powder, soybean milk, egg powder,

sauce, syrup.
------------------------------------------------------------------
Metal, metallurgy mining industry; aluminum powder, ceruse, copper powder, ore alloy powder,

welding rod powder, dioxide manganese, electrolyse copper powder, electomagnetism materials,

rubbing powder, fire-proof material, kaolin, lime, alumina, heavy calcium carbonate,quartz.Social

pollution disposed; disposed oil, disposed water, disposed dye waste water,assistant detergent,

active carbon.

Model	Power (Kw)	Sieving D iameter (mm)	Dimension L×W×H (mm)	layer


1S ZYD-400-2S 3S	0.18	320	580×580×560	1
			580×580×660	2
			580×580×760	3
1S ZYD-600-2S 3S	0.55	550	800×800×680	1
			800×800×780	2
			800×800×880	3
1S ZYD-800-2S 3S	0.75	750	900×900×780	1
			900×900×930	2
			900×900×1080	3
1S ZYD-1000-2S 3S	1.5	950	1160×1160×880	1
			1160×1160×1030	2
			1160×1160×1180	3
1S ZYD-1200-2S 3S	1.75	1150	1360×1360×980	1
			1360×1360×1160	2
			1360×1360×1360	3
1S ZYD-1500-2S 3S	2.2	1450	1850×1850×1130	1
			1850×1850×1330	2
			1850×1850×1550	3
1S ZYD-1500-2S 3S	2.2	1750	2200×2200×1360	1
			2200×2200×1460	2
			2200×2200×1680	3

Place of Origin:	Henan China (Mainland)	Brand Name:	Zhenying	Model Number:	ZYD
Type:	vibrating sieve	Color:	Blue & White	Material:	Stainless Steel SUS304
Customization:	Available	OEM:	Available	Instruction Video:	Available
