1,SS304,SS316L materials
2,Filter accuracy:5-200um
3,Type:Vertical and Horizontal (Optional)
Activated Carbon Water Filter Introduction
Activated carbon (AC) is a natural material derived from bituminous coal, lignite, wood, Coconut shell etc., activated by steam and other means, and each one have different adsorption properties (e.g. bituminous carbon for high chlorine reduction capacity). Some manufacturers use various blends of carbon to achieve specific water quality and contaminants reduction (e.g. coconut shell carbon for "sweet taste").
Our granular activated carbons and filtration systems remove Organic and inorganic contaminants from groundwater, surface and process water, wastewater and air/vapor streams. With permanent or removable adsorber equipment options and carbons backed by an industry-leading quality assurance program, Konche gives customers the right configuration for their application and flowrate, while also assuring optimal carbon utilization.
Activated Carbon Water Filter Specification
| Diameter * Height * Thickness (Stainless steel /Carbon steel) | Flow Rate | Inlet & Outlet (DN) | |||
| MM | INCH | T/H | GPM | MM | INCH |
| Φ350*1678*1.5 (3) | 13.8*66*0.06(0.12) | 1.5*2 | 7-9 | 20 | 0.78 |
| Φ406*1720*2 (3) | 16*67.7*0.08(0.12) | 2-2.5 | 9-11 | 25 | 0.98 |
| Φ508*1810*2 (3) | 20*71.3*0.08(0.12) | 2-3 | 9-13 | 25 | 0.98 |
| Φ606*1855*2 (3) | 23.9*73*0.08(0.12) | 3-5 | 13-22 | 32 | 1.26 |
| Φ707*1975*2 (3) | 27.8*77.8*0.08(0.12) | 5-6 | 22-26 | 32 | 1.26 |
| Φ807*2075*2 (3) | 31.8*81.7*0.08(0.12) | 6-8 | 26-35 | 32 | 1.26 |
| Φ1000*2160*2 (4) | 39.4*85*0.08(0.16) | 10-12 | 44-53 | 40 | 1.57 |
| Φ1200*2685*3 (4) | 47.2*105.7*0.12(0.16) | 12-15 | 53-66 | 50 | 1.97 |
| Φ1400*2800*3 (6) | 55*110.2*0.12(0.24) | 15-22 | 66-97 | 50 | 1.97 |
| Φ1500*2815*3 (6) | 59*110.8*0.12(0.24) | 18-25 | 79-110 | 65 | 2.56 |
| Φ1600*2965*4 (6) | 63*116.7*0.16(0.24) | 20-30 | 88-132 | 65 | 2.56 |
| Φ1808*3150*4 (6) | 71*124*016(0.24) | 30-40 | 132-176 | 80 | 3.15 |
| Φ2000*3600*4 (8) | 78.7*142*0.16(0.31) | 40-50 | 176-220 | 100 | 3.94 |
| Φ2200*3760*5 (8) | 86.6*148*0.2(0.31) | 50-60 | 220-264 | 125 | 4.92 |
| Φ2400*3910*6 (8) | 94.5*154*0.24(0.31) | 60-80 | 264-352 | 125 | 4.92 |
| Φ2500*3980*6 (8) | 98.4*157*0.24(0.31) | 80-90 | 352-396 | 150 | 5.9 |
| Φ2600*4050*6 (10) | 102.4*159*0.24(0.39) | 90-100 | 396-440 | 150 | 5.9 |
| Φ2800*4200*8 (10) | 110*165*0.31(0.39) | 100-120 | 440-528 | 150 | 5.9 |
| Φ3000*4500*8 (10) | 118*177*0.31(0.39) | 120-140 | 528-616 | 200 | 7.87 |
Temperature: 5-50°C
Flow rate: 10-12m/h
Backwash intension: 16-18L/m2·s
Backwash time: 5-10min
Activated Carbon Water Filter Equipment Feature
1. Reasonable structure and large space
Water distribution plate sets up in seal head, can increase efficiently the purified space
2. No leakage, Distribution plate in the inlet and outlet, with bonnet, water distributing evenly, no leakage of the filter materials
3. Corrosion prevention Epoxy resin inside the filter, corrosion prevention outside, avoid secondary pollution
4. Convenient maintenance. Worker can enter into the equipment to repair; filter cap can be replaced inside the cartridge without dismantling pipeline
| Place of Origin: |
Guangdong China (Mainland)
|
Brand Name: |
OEM
|
Model Number: |
KC-FD
|
| Water Capacity: |
2-140T/H
|
Material: |
Stainless Steel
|
Medium Material: |
Activated Carbon
|
| Function: |
Water Filter
|
Structure: |
Filtering Machine
|
Type: |
Filter Housing
|
|
|
|
|
|
|
|
|
|
|
|
|
