Coconut shell fired sprial pipes steam boiler,China Yongxing price supplier

Coconut shell fired sprial pipes steam boiler

FOB Price:Price can be negotiated

Production Capacity:1000 Set/Sets per Year

Payment Terms: US $1,500 - 150,000 / Set

Update Time:2023-04-29

Contact Supplier

Product Description

Combustion equipment activities grate.Solve the old boiler tube sheet cracks,Low thermal efficiency,Coal poor adaptability

The boiler plate arch pipe, spiral pipe technologies.Solve the old boiler tube sheet cracks,Low thermal efficiency,Coal poor adaptability,and other Frequently Asked Questions.

Combustion process:

Fuel into the combustion chamber in the grate,Combustion flue gas into the convection

region,then through the smoke box into the spiral pipe,after dust collector,fan work,finally released to the atmosphere through the chimney.

DZH Coal-fired boiler technology parameter Table
Type	DZH0.5-0.7-S	DZH1-0.7-S	DZH2-0.7-S	DZH4-0.7-S
Rated Vaporizing Amount	0.5T/H	1T/H	2T/H	4T/H
Rated Steam Pressure	0.7Mpa	0.7Mpa	0.7Mpa	1.25Mpa
Rated Steam Temperature	170.4	170.4	170.4	193.3
Inlet Water Temperature	20	20	20	20
Heating Surface	20.65sqm	30.4sqm	56.2sqm	120.1sqm
Fire Grate Surface	0.84sqm	1.47sqm	2.88sqm	4.15sqm
Design Fuel	Biomass	Biomass	Biomass	Biomass
Transport Dimension	310018102400	390021002900	437023503195	525026003430
(LxWxH)	mm	mm	mm	mm
Transport Weight	6.07t	7.5t	10t	21t

Type:	Other	Usage:	Industrial	Structure:	Water Tube
Pressure:	Low Pressure,0.7/1.25Mpa	Style:	Horizontal	Fuel:	Coal-fired
Place of Origin:	Henan China (Mainland)	Brand Name:	Yongxing	Model Number:	DZH
Output:	Steam

Company Profile

Name: Henan Yongxing Boiler Group Co., Ltd.

Main Products: Steam Boiler,Hot Water Boiler,Thermal Oil Heater,Hot Air Generator,Autoclave,Wood Processing Equipment,Gas Boiler

Business Type: Manufacturer, Trading Company

Total Employees: 501 - 1000 People

Established Year: 2005

Main Markets: Domestic Market, Southeast Asia, South Asia, Eastern Asia, Mid East

Address: Zijingshan Road

Enterprise History
Since our establishment in 1970s, we have developed from a small enterprise into a comprehensive group, integrating the R&D, manufacture and sale of boilers and related products.

Enterprise Strength
We have 1500 staff members, including 120 professional engineers with high education and 1000 skilled workers with strict training. We also boast complete production lines, ranging from advanced manufacturing facilities to sophisticated inspection equipment. Thus, we can ensure high productivity and efficient production. Meanwhile, backed by stable material suppliers, we produce up to 100 boilers monthly. 56% of our products are for export.

Enterprise Markets
Selling well throughout domestic market, our products are also warmly welcomed by clients in Southeast Asia and the Middle East. We are looking forward to cooperating with more clients worldwide for common development and mutual benefits. Contact us today to benefit from what we offer. more
