Coconut water prcossing PP Membrane Cartridge/ micron filters/mineral water filter machine,China T.S.Filter price supplier

Coconut water prcossing PP Membrane Cartridge/ micron filters/mineral water filter machine

FOB Price:Price can be negotiated

Production Capacity:20000 Piece/Pieces per Month

Payment Terms: US $2 - 10 / Piece

Update Time:2014-09-16

Contact Supplier

Product Description

1.PP pleated high purity cartridges
2.large dirt-holding capacity
3.Filter cartridge with long life and high flow rate

Product Description

Economical water filter cartridges with polypropylene media

Place of Origin: Zhejiang China Brand Name: T.S.Filter Model Number:DPP

Filter Cartridge Products Picture:

Filter cartridge Specification:

Material of construction
media	PP
inner core	PP/SUS304
out support layer	PP
inside support layer	PP
cage	PP
end caps	PP
O-rings/gasket	silicone/nitrile/epdm/teflon/viton
sealing technology	thermal bonding,no adhesives
Dimensions
Outer diameter	69mm(2.75'')
inner diameter	33mm(1.30'')
Length(based on DOE adapter)	10''/20''/30''/40''
filtration area(m2)	0.65m2 per 10''
pore size(um)	0.1,0.2,0.45,1,5
operating conditions
maximum differential pressure
normal flow direction	4.2bar(60 psi) at 25°C(77°F)
reverse flow direction	2.1bar(30 psi) at 25°C(77°F)
normal operating temperature	up to 55°C ( 131°F )
max operating temperature	80°C ( 172°F )
PH value compatibility	1-13
particular removal efficiency(%)	99.98%
Application	prefiltration and guard filtration
Sterilization	not recommened

Material safety

Meet the current FDA and 2002/72/EC standard.

Endotoxin:<0.25EU/ml

Extractables:0.03g/10''

Cartridge purity

Free of surfactants, resins, binders and adhesives.
Standard: Clean and flushed with Pyrogen-free water.
Vacuum packing

Typical Applications

Pharmaceutical; APIs, Biologics;
Plating solution; Ink

Fine chemicals;

Foo and beverage,wine,beer,mineral water;

Semi-conductor.LCD disply,discs

Typical water flow rate (10”)

Liquid Retention Ratings (um) Test

Order Information

Certificate

Place of Origin:	Zhejiang China (Mainland)	Brand Name:	T.S.Filter	Model Number:	DPP filter
Brand:	T.S.Filter	filter media:	polypropylene	inner core:	PP/SUS304
Model::	DPP cheap water filter cartridges	filter length:	10'',20'',30'',40''	filter diameter:	69mm(out);33mm(inner)
filtration area:	0.65m2(10'')	application:	for prefiltration and guard filtrationbeer brewing machine	efficiency:	99.98%
Micron(um):	0.1,0.2,0.45,1,5,20,40
