we may offer 50-10000ton per day of Corn Starch processing machine

1) Purifying: Before going to storage bin, pre-purifying is done to eliminate big and small foreign substance which will be sent to germ cake collection section. There is a device near storage bin, it has clean, de-stone, de-dust functions. Purified corn is sent to steeping section.

(2) Steeping: Counter current steeping principle is adopted to make corn become soft in steeping tank. Acid is heated and remains 50°C when circulating in all tanks. Dipped corn is pumped to crashing stage, sending to wet corn storage after dewatering.

(3) Sulfurous acid making: Sulfur is burned in furnace, getting SO2 gas, goes to absorption tower with china rings. Water is sprayed down, mixed with rising SO2 gas to get sulfurous acid.

(4) Crash and germ separation: Steeped corn is sent to 1st germ mill from wet corn storage bin. Crashed corn is pumped into 1st Germ Cyclone and screen, and then goes to 2nd mill for further crush. Germ goes to 2nd germ cyclone then back to previous tank.

(5) Finely milling and fiber wash, dewater, drying: In pin mill, the degermed corn is multi--strongly crashed to remove fiber off. Fiber is sent to multi-stage washing screen for recovering the balance starch. Cleaned fiber goes to screw presser for dewatering then goes into bundle dryer for drying to mix with corn slurry for making animal feed product.

(6) Protein separation and starch washing: Starch milk goes to primary separator for gluten separation. Cleaned starch goes to 12 stages cyclones for final washing to remove the tiny foreign items.

(7) Starch dewater and drying: Fine starch milk is dewatered by peeler centrifuge, the starch is sent to air flow dryer for making dry starch product in which moisture should be less than 14
