Customized aerated drinks filling machine ,2013 new machinery for soda filling,China Longway price supplier

Customized aerated drinks filling machine ,2013 new machinery for soda filling

FOB Price:Price can be negotiated

Production Capacity:10SET

Payment Terms: TT

Update Time:2015-02-12

Contact Supplier

Product Description

Specifications

this machie is mainly used in carbonated beverage filling operations. the operation is convenient high production and profit

The series equipment is used in production of polyester bottle-packing carbonate drink, such as Coca cola, Pepsi-cola, Sprite drink etc.
It can carry out washing bottle, filling and capping of one machine. The whole machine designing is reasonable. The appearance is beautiful and the maintenance is convenient. It adopts hanging type conveying-bottle structure to make changing bottle model more convenient, faster and more easy. The main machine adopts advanced PLC control technology. The key electric elements are adopt international famous products.Machine Accessories

Filling temperature: 3-5degree
Total power: 4.2KW
Conveyor form: air conveyor
Bottle neck-hanging: GERMAN KRONES
Washing: new type pf bottle neck hanging: GERMAN KRONES
Filling: new type of filling valve GERMAN KRONES
Sealing: magnetic capping technique GERMAN KRONES
Touch screen: TAIWAN WENVIEW
Transducer: American EMERSON
Main electric: GERMAN SIEMENS
PLC: JAPAN OMRON
Approach switch: Korea AUTONICS
Light Fiber switch: Korea AUTONICS
Reducer: HANGZHOU JIE BRAND
Motor: shanghai
Pneumatic elements: TAIWAN AIRTA

Main Techinical Specification

Model:	DCGF18-18-6		DCGF24-24-8	DCGF32-32-12		DCGF40-40-12
Capacity :500ml	5000		8000	12000		16000
Bottle shape:	roud or square
PET bottle: (mm)	(Bottle Diameter):φ50-.φ110mm (Height):150-340mm
Cap:	PE srew cap
Filling precision:	≤±5mm
Filling pressure:(Mpa)	0.15-0.35	0.15-0.35		0.15-0.35	0.15-0.35
Rinsing pressure:(Mpa)	0.2-0.25	0.2-0.25		0.2-0.25	0.2-0.25
Filling volume :(L)	3.5	4		6	8
Overall size:(mm)	24501800 2350	27802200 2350		36002650 2350	38002950 2400
Weight: (kg)	3500	4500		5500	6500
