Font applications
The line will wash dates by cold or warm water or steam as needed and demand
The production capacity of the line ranges from / 250 / kg per hour and up to / 2 / ton per hour. It is made entirely of stainless steel food / 304 / L
The line consists of the following equipment:
- Primary Server Bus Routing:
- The walkway is equipped with a rubber-resistant mat
- Powered by an engine and a speed control device to suit the production line.
- With a bucket to unload the dates so that the dates are received and transferred to the beginning of the production line.
- Vibrating Screening of impurities and chopsticks.
- The vibrator sieves and dislodges impurities and dates from the dates by a turbine fan
- The vibrator is equipped with white steel bars (stainless steel / 304L) allowing the passage of waste
- Mechanical vibration is an impermeable vibration that does not affect the outer layer of dates
- Manual sorting process:
- The BIOS is operated by a motor with a speed control device.
- The process of carrying the dates and moving from the vibrator sieve to the washing stage and the workers on both sides of the process to sort the unwanted grains and put it on the special path
- Ha and the proper dates are completing its way to the production line.
- The walkway is equipped with three intermediate tracks of the production line and two side tracks of the waste.
- Dates are moved by a rubber-based quilt.
- Laundry:
- Dates are received from the hand sorting process and automatic flipping and washing are initiated.
- The dates carry on a plastic mat in three stages for the process of washing and flipping to ensure cleaning dates from all sides and the preservation of the outer casing of dates
- Dates are washed with plastic sprays of cold water or steel for hot water or steam.
- After the washing process, the dates complete the passage on the plastic mats to be filtered from the water and flush the water with a high pressure turbine fan and prepare dates for the drying phase.
- The motor is equipped with a water pump and a motor with a speed control device to match the speed of the production line.
-
Drying Furnace:
The dates are loaded and transported by a mat made of white steel (stainless steel / 304 / L).
The drying process is carried out with hot air at temperatures above 90 ° C.
The dates are dried from the water and dates are heated and prepared for the final packaging stage after leaving the tunnel.
The tunnel can be supplied with Violet Violet to sterilize the dates of the bacterium and the gareth.
The heating process is carried out by electric heaters
Dates are cooled in the final phase of the tunnel by a low-pressure, high-pressure turbine fan
The requirements of the line by wishing to open a factory to prepare and fill dates
-
- The average area required for the production line except the cooling rooms and warehouses / 300 / square meters.
- Number of middle workers / 8 workers in addition to maintenance technicians.
- Clean water tank for cleaning. Tank capacity: 2000 / L
- Land level factory to install equipment straight
-
Optional additions:
- Vibrator to filter the water after the washing process and before the drainage tunnel
- Laundry by pressing / 120 / bar to wash the line after finishing the line
- Plastic cover for wrapping the line at the end of the season of dates to protect it from dust and atmospheric factors.
- Ultraviolet sterilization tunnel
