DB-B70 paper bowl machine,China DEBAO price supplier

DB-B70 paper bowl machine

FOB Price:Price can be negotiated

Production Capacity:20sets

Payment Terms: FOB , CIF

Update Time:2025-02-15

Contact Supplier

Product Description

Description:

DB-B70 Paper Bowl Forming Machine is an automatic forming machine. It has improved the speed and quality basing on DB-L50 Bowl Forming Machine. It has many procedures, including feeding, Sealing, filling silicone oil, punching bottom, two-procedure bottom heating, knurling, curling, roll- watering line, putting down bowl & checking photoelectric , troubles warning, counting, etc. It is the ideal equipment in producing the large content or the big aperture paper containers, such as soup bowl, fast noodles bowl and so on.

Main technical Parameter

Model	DB-B70	DB-2B70	DB-B80	DB-2B80	DB-22	DB-2C22
production capacity	40-50pcs/min		35-45pcs/min		15-30pcs/min
required paper	150-250gsm one side PE coated paper	150-380gsm two side PE coated paper	150-250gsm one side PE coated paper	150-250gsm two side PE coated paper	150-250gsm one side PE coated paper	150-250gsm two side PE coated paper
container capacities	(A)Ф60-120mm;(B)60-115mm; (C)Ф50-97mm;(D)4.5-11mm		(A)Ф90-155mm;(B)60-115mm; (C)Ф80-125mm;(D)6-12mm		(A)Ф150-240mm;(B)100-180mm; (C)Ф130-180mm;(D)8-15mm
total power	380v 50hz 5/9kw		380v 50hz 7/11kw		380v 50hz 11/15kw
weight	1500kg		1800kg		2500kg
overall dimensions	2800×1400×1900mm		3000×1600×1900mm		3700×2100×2300mm

Other Products

DB-L12 paper cup machine

DEBAO-600A high speed paper cup machine

DB-B70 paper bowl machine

ZDM-1 Automatic indentation roll paper die cutting machine

Company Profile

Name: Zhejiang New Debao Machinery Co.,Ltd

Main Products: Paper cup machine,paper bowl machine,die cutting machine,printing machine, paper cup/bowl jacket forming machine,paper cup/bowl hollow machine,ice-cream paper cone forming machine

Business Type: Manufacture & Trade

Total Employees: 100 ~ 500

Established Year: 1999

Total Annual Revenue: US$1 Million - US$2.5 Million

Main Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe,

Address: NanAn Industrial Zone Feiyun Town Ruian City zhejiang China

DeBao, China paper tableware machine maker, we offer paper cup forming machine for making paper cup, paper bowls, KCF home packing bowls and take-out paper containers.

Zhejiang New Debao Machinery Co., Ltd. specializes in producing series of paper containers automatic forming machinery.

Our factory boasts advanced equipment, strong technological strength and rich manufacturing experience. We study current products and future trend to develop novel products such as single coating film paper cup forming machines, paper bowl forming machines, paste bowl machines, disk box machines, shower membrane machines, cutting machines and creasing and cutting machines.

These machines feature complete functions, steady performance, beautiful configuration and can produce 2.5 to 200 ounce (60ml/C 6, 000ml) paper cups, paper bowls, KCF home packing big bowls by changing their mould. They enjoys great popularity in this field because of their advanced technology.

Placing great importance to technology, our company cooperates closely with many universities, such as Tsinghua University and Shanghai Jiaotong University. We constantly improve ourselves to provide customers with quality products and first rate after-sales service.

If you are interested in any of our products, please feel free to contact us.
