Desiccated coconut drying machine,China JIANDA price supplier

Desiccated coconut drying machine

FOB Price:Price can be negotiated

Production Capacity:1 Set/Sets per Month

Payment Terms: US $1 - 1,000,000 / Set

Update Time:2021-10-18

Contact Supplier

Product Description

apply to Dehydrated vegetable,union,fruit, organic,plastic, rubber, wood,electronics elements,calcium,chemical products,food

Descriptions

Raw materials are spreaded on the conveying belt through suitable auxiliary mechanism such as distributor, vibrating belt, pulverizer of granulator,belt passes the channel which containing one or several heating units; heating unit is equipped with air heater and circle system. Each channel has one or several damp exhaust system. When raw material is transited, hot air passes through or over it. In this way it makes raw material dry uniformly

F eatures

1. mount of air, heating temperature, time of material sticking on the belt and velocity of feeding material can be adjusted in order to obtain the best drying effect.

2. Equipments configuration is very flexible. It can use the netlike belt washing system and cooling raw material system

3. Hot air can be circular Unique air dividing device, it makes hot air distribute uniformly; this can guarantee products quality

4. Heating source can be selected from steam, conducting heat Oil, electricity, coal furnace and oil burner

we can design it acoording to the requirement

Typical products

Dehydrated vegetable, granule feedstuff, monosodium glutamate, chicken abstract, desiccated coconut, organic pigment,synthetic rubber, medicines, small wood products, plastic products, aging and solidifying electronics elements, calcium carbonate, white carbon and black dyestuff.

drying machine

Model		DW-1.2-8	DW-1.2-10		DW-1.6-8		DW-1.6-10		DW-2-8		DW-2-10	DW-2-20
Unit number		4	5		4		5		4		5	10
Belt width (m)		1.2	1.2		1.6		1.6		2		2	2
Drying setion length(m)		8	10		8		10		8		10	20
Thickness of the material to be covered (mm)		≤60
Temperature (°C)		50~140
Steam pressure (Mpa)		0.2~0.8
Steam consumption (kg/h)		120~300		150~375		150~375		170~470		180~500	225~600	450~1200
Drying time (h)		0.2~1.2		0.25~1.5		0.2~1.2		0.25~1.5		0.2~1.2	0.25~1.5	0.5~3
Drying capacity (kg/h)		60~160		80~220		75~220		95~250		100~260	120~300	240~600
Total power of the equipment (kw)		11.4		13.6		11.4		13.6		14.7	15.8	36.8
Overall dimensions	L(m)	9.56		11.56		9.56		11.56		9.56	11.56	21.56
	W(m)	1.49		1.49		1.9		1.9		2.32	2.32	2.32
	H(m)	2.3		2.3		2.4		2.4		2.5	2.5	2.5
Weight(kg)		4500		5600		5300		6400		6200	7500	14000

Place of Origin:	Jiangsu China (Mainland)	Brand Name:	JIANDA	Model Number:	DW
Application:	Granules	Type:	Drying Machine

Company Profile

Name: Changzhou Jianda Dry Equipment Co., Ltd.

Main Products: Drying Equipment,Granulating Equipment,Mixing Equipment,Crushing Equipment

Business Type: Manufacturer

Total Employees: 101 - 200 People

Established Year: 1993

Main Markets: Domestic Market, North America, Mid East, South America, Central America

Address: Dongqing Industrial Park, Zhenglu Town, Wujin District

Changzhou Jianda Drying Equipment Co., Ltd. was founded in 1980. We are the first Sino-USA joint venture company in drying industry, enjoying a well-known brand name specializing in drying equipment. Our company is located in Dongqin Industrial Development Area, the center of Yangtze River Delta. We cover more than 50 thousand square meters and hold fixed assets of 8 million USD.

Through over twenty years' sound development, we have been ranked as one of the top producers in drying equipment industry in China. We have developed 36 kinds of main products and more than 260 special models with high quality. Those products are widely applied in chemistry, foodstuff, pharmaceutical, electronic industry, etc. We can manufacture more than 1000 sets of different equipment for drying, granulating, mixing and crushing.

Since 1993, we have introduced the most advanced technique and management experience from foreign partner - Tony International Trading Inc. Since then, our technology and management have achieved developed international standards. We have been designing meticulously and innovating continually. Many products are unique and reach international advanced level. Depends on our powerful strength, high effective organization, outstanding talents, superior technique and excellent reliable service, we always keep at top level and hold unique position in this highly competitive industry.

Our mission:
To be the undisputed leader in drying equipment field, we are passionately committed to supplying perfect drying technique solutions for worldwide clients

Our goal:
To build world first-class drying equipment research centre dedicated in new technology development and set up systemic customer relationship management system, we do everything for customers' satisfaction.

We possess powerful research capability. Our research team is led by the senior members of China Drying Technology Group and Chemical Industry Engineering Association. Those researchers take charge of technique design, process improvement and quality inspection. They have built strong foundation for our rapid development.

Through our own efforts, we have owned over 10 national patents and credit AAA grade certificate for eight years. Our products have won national gold prize for several times. In 1993, we were one of the first drying equipment enterprises with self-supporting export license authorized by the Ministry of Foreign Trade and Economic Cooperation. In 2006, our dryer was certificated by government as the most famous brand name in China.In 2008, JIANDA Brand CT Series Dry Oven is certificated to be complied with CE Standards by UKTC.
We have set up systemic customer management system. We insist on good faith and strictly abided by the "quality guarantee policies". When receiving complaints, we will reply within two hours. In case of shutdown problems, depending on respective distances, market network will be activated to solve problems at the fastest speed and in the shortest time to indicate the sense of no distance between us. Customers are full of confidence about our service.

Our sales network covers domestic and abroad. Products are well sold in China and spread all over world, such as America, Japan, Australia, New Zealand, Iran, Indonesia, Philippines, Russia, South Korea, Cyprus, Mexico, Egypt, South Africa, Peru, Greece, Ghana, Brazil and United Kingdom.

We are a top producer in drying industry, which was created in midst of reform tide and is developing in the process of new global economy development. We will closely follow the newest trend, positively track the latest development and keep up with worldwide new drying technology. more
