1.intergate design, easy installation
2.all stainless steel, fit for food degree
3.stainless steel mash, long work time
1 . Combining the latest technology and years experience int a whole; Key components introduced abroad,long service life,low maintenance cost;
2..All parts contact with material are stainless steel,no material contamination; Sieve basket is calibrated through dynamic equilibrium by domestic authority body.
3.Sieve made from laser perforating on titanium alloy plate; To facilitate the automatic design for Centrifugal sieve group,CIP system and chain automatic control can be easily realized;
4.. Advanced surface treatment technology ensuring good looking and resistance of Oil and dirt.
Nozzles tested by strict examination in pressure and flow rate.
5. Big capacity, low power consumption, stable operation, high starch extraction and easy installation; Widely used for starch extraction in starch processing factory.
Main specifications:
Diameter of screen basket (mm) |
910 |
Speed of main spindle(rpm) |
1100~1400 |
Effective capacity (m 3 /h) |
40~60 |
Sieve diameter (μm) |
125 |
Power of motor (KW) |
22 |
Outside dimensions of Packing (mm) (length × width × height) |
1500x1650x2250mm |
Gross weight of the equipment (kgs) |
1500 |
Material |
product-contacting parts made of stainless steel |
key equipment of starch line ;
Finished product :
Place of Origin: |
Henan China (Mainland)
|
Brand Name: |
ZY
|
Model Number: |
CS
|
Type: |
starch extraction
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
material: |
stainless steel
|
color: |
slilvery white
|
Power of motor (KW): |
22kw/pcs
|
packing: |
bare packing
|
weight: |
1500kg
|
warranty: |
1 year
|
Contact: |
0086-371-67857610
|
Terms of payment: |
T/T
|
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
