direct factory three D-Rotary Vibrating sieve cocoa powder screening machine,China XinXiang TongXin price supplier

direct factory three D-Rotary Vibrating sieve cocoa powder screening machine

FOB Price:Price can be negotiated

Production Capacity:100 Set/Sets per Month

Payment Terms: US $950 - 5,000 / Set

Update Time:2014-09-20

Contact Supplier

Product Description

round separator machine
1.High efficiency screening
2.Mesh size: 2-500 mesh
3.Layer:1-5
4.Large capacity

Xinxiang Tongxin Machinery Limited Liability Company

Product

material:

(1)All stainless steel

(2)Contact part stainless steel,other part carbon steel

(3)All carbon steel

standard:

International standard ISO3310

( Machinery Directive CE certificate)2006/42/EC

feature :

COCOA POWDER screening machine

(1)Elegant design & durable, available for any powder and viscous liquid, easy moving and

space saving

(2) High screening efficiency - screen up to 500 mesh(0.028mm) ontact part stainless steel,other part carbon steel

(3)Easy to operate, easy to change the screen cloth(3-5 minutes), easy to clean

(4) Automatic discharge of impurities and coarse materials, continuous operation

OEM serivce:

YES

Specifications:

Model	D iameter of sc reen S urface	Effective Screening Area	Measuring Range	Deck	Power
	(mm)	(m 2 )	(mm)		( kw )
XZS-600	560	0.2281	Screen up to 0.028mm	1-5	0.55
XZS-800	760	0.4183		1-5	0.75
XZS-1000	950/970	0.6359		1-5	1.1
XZS-1200	1130	0.9499		1-5	1.5
XZS-1500	1470	1.5386		1-5	2.2
XZS-1800	1770	2.2687		1- 3	3.0
XZS-2000	1886	2.7922		1- 3	3.7

cocoa powder screening machine

Note: This is only for reference and products specification should be studied from the real products

provided

Price

payment:

L/C,T/T,Western Union

Port:

Shanghai, Qingdao, Tianjin, Dalian

MOQ:

10pcs

Contact us

M P:

13503801371

Tel:

86-0373-5860668

Fax:

86-0373-3388038

Add:

No. 32, Sizhuangding Industrial Park, Muye Dist., Xinxiang, Henan, China (Mainland)

Product Image

Production process

cocoa powder screening machine

Structure

Applied scope

Product sales

Our company's products have provided to many domestic famous enterprises and listed companies, such as Shenhua Group of China, Tang Electric Power Group, Zan dem Group, Science and Technology of Beijing Antai, Chongqing Yamaha, White Dove(Group)Co.LTD, COFCO, CAEC, SINOPEC YANGZI PETROCHEMICAL CO.,LTD, Peking University, Central South University, Chinese Academy of Sciences, Pharmaceutical Administration in China, Administration of Traditional Chinese Medicine, Tsinghua University, Xiamen University, Xiamen Medical College of Higher Education and so on. We have got their favorable comments. At the same time, our company exports to the United State, United Kingdom, Russia, Thailand, Singapore, Philippines, Australia, Malaysia, , Uzbekistan, Venezuela, India, Indonesia, Vietnam, Zimbabwe, New Zealand, Colombia, the Netherlands, Poland, Saudi Arabia, Romania, Chile, Kazakhstan, Sweden, Angola and some other countries, we also get their favorable comments.

Type:	ISO	Material:	carbon/stainless steel	Material Feature:	Heat Resistant
Structure:	round separator	Load Capacity:	large as you required	Place of Origin:	China (Mainland)
Brand Name:	XinXiang TongXin	Model Number:	XZS400---XZS2000	Voltage:	220/380V
Power(W):	0.25-3.7kw	Dimension(LWH):	Diameter 400-2000mm	Certification:	ISO,ISO9001:2008
After-sales Service Provided:	Engineers available to service machinery overseas	round saparator machine Construction:	Carbon steel, stainless steel	Diameter:	400-2000mm
Screen mesh:	2-500 mesh	round saparator machine Deck:	1-5	round saparator machine Type:	Circular/round
round saparator machine Motor:	Single vertical motor	Application:	Classification, Filteration, Washing
