Dongfeng 8*4 drive Cummins engine dry bulk cement Powder truck
1.Trailer with 12 pieces of tyres
2.MOQ:1 set
Dongfeng 8*4 drive Cummins engine dry bulk cement powder truck
We are able to manufacture the trailers according to customer's need.
We are able to load trailers into 40/45 feet containers to save sea freight for customers.
Please write to us, and we will reply you within 2 hours!
Our products:
SEMI-TRAILER:
flat bed semi trailer and skeleton semi trailer ,used for transport 20ft,40ft,45ft,53ft container or steel etc. Size:7160/12350/14200/14850/16500x2500x1490mm;
BPW/FUWA AXLE
DOUBLE COIN / TRIANGLE BRAND TIRE
2,Professional Packing:
According to customer's loaction and the vehicles size,we provide professional packing can save great sea freight for customers.
FLAT BED / FENCE PLATE SEMI-TRAILER LOADING INTO CONTAINER
Three units to be packed into one unit to save sea freight
DUMP SEMI-TRAILER LOADING INTO 40 HQ CONTIANER
Tank SEMI-TRAILER LODING INTO CONTAINER
13.6 METERS TAIL CUT BEFORE LOADING INTO CONTIANER
3,Production line
4.Sample Specification for Dongfeng 8*4 drive Cummins engine dry bulk cement powder truck:
(2/3 axles)
|
Specification |
|
| Tear Weight |
6200Kg |
| Payload |
40,000 Kg |
| Total weight |
46200Kg |
| Overall Length |
12355mm |
| Overall width |
2490mm |
| Overall height |
1480mm |
| Wheel track |
1830mm |
| Wheelbase |
7900mm +1310mm |
| Standard Specifications Trailer frame structure |
Heavy duty extra & extra durability designed opting for high tensile steel Q345 welded by automated submerged MIG or ARC process MAIN I BEAM: Height 500mm Top flange width 146mm and its thickness 14mm Middle flange thickness 8mm Bottom flange width 140mm and its thickness 16mm high tensile steel Q345 SIDE BEAM: "C " CHANNEL Height 180mm x width 68mm x thickness 7mm , high tensile steel Q235 TRAILER FRONT SIDE CHANNEL: Height 180mm x width 68mm x thickness7mm , high tensile steel Q235 TRAILER REAR SIDE CHANNEL: Height 250mm x width 78mm x thickness7mm , high tensile steel Q235 CROSS MEMBER: "C" CHANNELS Height 100mm x width 37mm x thickness 3mm high tensile steel Q235 No. of pcs used in one trailer: 17 cross member at the locks :Height 160mm x width 63mm x thickness 6.5mm, high tensile steel Q235 No. of pcs used in one trailer: 6 |
| Floor |
Chequered steel sheet 3mm thickness. |
| Axles |
2 units of BPW 14 ton axle. BPW Meizhou Axle Co Ltd, Xietian Chengdong Town, Meixian Meizhou, Guangdong China |
| Suspension |
Mechanical Tandem 2 axles suspension BAOHUA with equalizer with 10 leafs. |
| Leaf spring |
10 leaves springs, 16mm x 90mm or 13x90mm |
| Kingpin |
1 unit of 2 inch SAE standard welded and Bolt on. JOST(China) Auto Component Co. Ltd, 888 Hanyuang Road Wuhan China |
| Landing gear |
Two -speed, manual operating, heavy duty landing gear JOST, lifting capacity is 28Ton & static capacity is 72ton dead load. JOST (Shanghai) Auto Component Co. Ltd or FUWA Landing gear,it's lifting capacity is 28Ton ,& static capacity is 72ton dead load. |
| Wheel rim |
9 units size 9.0x22.5 Rim for tubeless tyres Zhengxing brand |
| Tyre |
9 units of 315/80 R22.5 tyre, Linglong or Hantai brand |
| Twist lock |
12 units of ISO standard-twist lock for 1x20ft; 2x20ft; 1x40ft container, the central locks can be laid down. |
| Spare wheel carrier |
2 set of Spare wheel carrier including a riser |
| Pneumatic braking system |
A system with emergency brake & parking brake, Dual line air brake, piggy back spring on all axles, two units of WABCO RE 6 relay valve, 4 units of T 30/30 spring brake chamber; 2 units of T 30 brake chamber, two unit of 40 L air tank; two unit of standard copper air-connector (WABCO)Guangdong FUWA Engineering Manufacturing Co. Ltd. |
| Electrical system |
1 unit of JAEGER POWAY, 24 v 7-pin ISO 1185 standard socket; tail lamp with turn signal, brake light & reflector, side lamp etc. One set of 7 core standard cable. |
| Painting |
Sand blasting processing on rust-proof protection, one coat of anticorrosive primer, two coats of finish urethane paint, Color as customer choice |
| Accessory |
ONE TOOLING BOX WITH A SET OF STANDARD TRAILER TOLL |
| Iron wall |
On the front side of trailer, iron wall sizes are height 1372mm, width 2490mm . |
| Storage box for U Iron |
To store 28 pcs of U iron Height x width = 127 x 63.5mm Length 1220mm Thickness = 5mm |
| Departure angle |
15 degree, |
| Standard Attachments |
Reflectors, side fastening hooks, water tank 45LTr, Hitch (towing hook), mudguard and fire extinguisher place |
| Warranty |
3 years warranty |
.
| Use: |
Truck Trailer
|
Type: |
Semi-Trailer,$keywords$
|
Material: |
Steel
|
| Certification: |
CCC,CCC/CE
|
Size: |
12.4*2.5*1.55 METERS
|
OEM No.: |
73847328472
|
| Max Payload: |
45 TONS
|
Place of Origin: |
Shandong China (Mainland)
|
Brand Name: |
CIMC
|
| Model Number: |
SCY-21TL
|
King Pin: |
90#/50#
|
Axle: |
BPW/FUWA Brand
|
| Tire: |
Triangle/Double coin
|
Suspension: |
Spring/Air suspension
|
Brake System: |
Double line air brakes
|
| Landing Gear: |
Two-speed, manual operation, heavy duty landing gear
|
ABS: |
Wabco
|
