| Product Name
|
Flat Plate Automatic Blister Packing Machine with Plexiglas Cover
|
| Product model
|
DPB-250E
|
| Product specify
|
It is suitable for capsule, tablet, big honey pill, candy, liquid, paste, one injector as well as irregular shape Al-plastic, paper-plastic composite and Al-Al sealing packaging in pharmacy, healthcare, food, cosmetics, medical equipment industry etc.
|
Instruction and features:
This product is a newly packaging machine designed for machine in our company; its function has reached domestic leading level. It is suitable for capsule, tablet, big honey pill, candy, liquid, paste, one injector as well as irregular shape Al-plastic, paper-plastic composite and Al-Al sealing packaging in pharmacy, healthcare, food, cosmetics, medical equipment industry etc. This machine is adopted with micro-computer PLC, frequency converter, touch panel operation, high automation; it is ideal blister packaging equipment. The product passed the provincial science and technology appraisal.
Blister forming, hot-sealing, lot number printing, avulsion line impressing and cutting etc all adopt mandrel orientation, each can move freely in the mandrel when shaking the hand wheel, and it has staff gauge, easy to adjust and exact orientation.
Manipulator towing adopted culms double pendulum device, increased traction adjustable scope of the itinerary (it can get to 180mm), which can fit for medicine-card packaging of different sizes. The machine can registration heating, positive forming, up and down moire, air cylinder heating sealing, automatic feeding, automatic lot number printing, automatic cutting die, easy to operate and credible running.
Forming positive pressure air distribution with mechanical punch, ensuring blister forming well, and could collocate exclusive Automatic Feeder. It could fit for the packaging of ampoule, needle, Xilin Bottle, big honey pill, medicine machine and some special shape etc.
Main transmission part adopts parallel axis and bevel wheel speed reducer, forming dies and hot-sealing dies and impressing dies adopt bolt orientation, with exact orientation, easy to change dies and material saving.
Detachable design make the machine can be easily carried and installed according to the requirement of user.
Notes:
It can optional add opposite sealing device with cursor trace.
It can optional Plexiglas Cover.
It can optional add ink-jet printer.
Main technical parameters:
| Cutting Frequency(Times/min)
|
6-50
|
| Production Capacity ( ten thous pics/h)
|
3.5-23
|
| Max Forming Areas And Depth(mm)
|
240*170*26 ( standard 240*150*14 )
|
| Stroke(mm)
|
40-160 (Can Be Lengthened To 180mm As User's Requirements)
|
| Standard Plate(mm)
|
80*57 ( Can Be Manufactured As User's Requirements)
|
| Air Pressure(Mpa)
|
0.4-0.6
|
| Air Supply
|
≥0.3m3/min
|
| Total Power
|
380V/220V 50Hz 6.2kw
|
| Main Motor Power (KW)
|
1.5
|
| PVC Hard Pieces(mm)
|
0.15-0.5*250
|
| PTP Aluminum Foil(mm)
|
0.02-0.035*250
|
| Dialysis Paper(mm)
|
50-100g*250
|
| Mould Cooling
|
Tap Water Or Circulating Water
|
| Overall Dimensions(mm)
|
3000*730*1600(L*W*H)
|
| Weight(Kg)
|
1600
|
Royal Pharmaceutical Machinery Limited is a specially factory mainly for produce pharmaceutical machinery , such as tablet press, capsule filling machine, High-speed pill machine, blister packing machine, given bag packing machine, tea bag packing machine, cartoning packing machine and mult- function labeling machine ,etc. And we have a branch factory mainly for produce: heat seal filter papers, non heat seal filter papers and coffee filter papers. Our filter papers had been passed American standard FDA, European standard SGS, Quality COC certificate, ISO, LFGB, analysis report, etc.
We have many users in aboard, they all benefit from our machines and packing material high quality and competitive price, welcome all the clients come to our factory to visit and send a inquiry to us. We are sure to give u a satisfied answer!
|
|
|
|
|
|
|
|
|
|
|
|
|
|
