DPP-140 Automatic Coating chewing gum Packing Machine Blister packaging,China HUALI price supplier

DPP-140 Automatic Coating chewing gum Packing Machine Blister packaging

FOB Price:Price can be negotiated

Production Capacity:10 Set/Sets per Month

Payment Terms: US $10,000 - 15,000 / Set

Update Time:2025-05-25

Contact Supplier

Product Description

Automatic Gum.html" style="text-decoration:underline;font-weight:bold;" target='_blank'> Chewing Gum Blister Packing Machine
1.High efficiency, low consumption
2.Easy operating
3.Energy saving
4.CE, ISO

DPP-140 Automatic Coating chewing gum Packing Machine Blister packaging

1. Applications:

1. Applications:

1). Travel scope can be adjusted.Mould is located by located groove so that it's easy to change mould. The machine heats the PVC through conduction and forms it through pressing and frothing.

2). Speed is shifted by stepless transducer.Adopt the interface of human-machine and PLC rogrammable controller. Adopt professional feeder and feed accurately.

3). The equipment of trace pressing,batch number printing and scrap-collecting can be chose.

4). Double stepping motor drive wheel to grip and tow wrapper,synchroning accurately.

5). The heating moulds will automatically separate when the machine stops,which contributes to protect the material between them and extend the machine's life.

2. Main Technical Data:

2. Main Technical Data:

Model		320A	250A	140A
Blanking frequency(times/min)		15-50	15-50	15-50
Sheet's quantity of one blanking(sheets)		5-6	3-4	1-2
Capacity(sheets/hour)		5400-18000	3600-12000	1800-6000
Appropriate for Capsule		10-150	10-140	10-130
Max Forming area and depth(mm)		320×130×13	250×120×13	140×110×13
Capacity of air compressor((m3/min) )		≥0.45	≥0.38	≥0.36
Power supply		380V 50HZ 12KW	380V 50Hz8.5KW	380V 50Hz 635KW
Wrapper specification(mm)	PVC	320×(0.2-0.5)	250×(0.2-0.5)	140×(0.2-0.5)
Wrapper specification(mm)	Aluminum foil	320×(0.02-0.035)	250×(0.02-0.035)	140×(0.02-0.035)
Overall dimensions(mm)		3800×718×1750	3200×650×1450	2850×530×1450
Part size(mm)		2000×718×1750	1750×650×1450	1450×550×1300
Part size(mm)		1800×718×1750	1450×650×1450	1400×550×1450
Weight(Kg)		2000	1700	700

3. Overall Sketch:

3. Overall Sketch:

Planform

1: PVC feeder 2: PVC transporting roller 3: Heating box 4: Forming mechanism 5: Medicine feeder 6: Touch-screen

7: PTP transporting roller 8: Heat-sealing mechanism 9: Trace-pressing mechanism

10: PTP feeding mechanism & scrap-collector 11: Tow mechanism

12: Blanking mechanism 13: Finished product output

4. Packed Samples:

4. Packed Samples:

5. Packing

5. Packing

6. Certificates:

6. Certificates:

7. The Factory Show:

7. The Factory Show:

Please contact us by following device:

: willie_chen1 Telephone:/whatsapp : 13958849272 Saler: willie chan

Type:	Blister Packaging Machine,Automatic chewing gum Blister Packing Machine	Condition:	New	Application:	Food,Commodity,Medical,Chemical,Machinery & Hardware
Automatic Grade:	Automatic	Driven Type:	Electric	Voltage:	380V
Power:	6.5KW	Place of Origin:	Zhejiang China (Mainland)	Brand Name:	HUALI
Model Number:	DPP-140A	Dimension(LWH):	1400X550X1300mm	Weight:	700KG,700kg
Certification:	CE, ISO	Warranty:	1 Year	After-sales Service Provided:	Engineers available to service machinery overseas
Material:	SS304	Pack product:	Capsule, candy, pill and so on	Color:	Silvery
Screen:	Touch Screen	Mold:	Changeable	Feed:	Automatical
Pack type:	Wooden case

Company Profile

Name: Ruian City Huali Pharmaceutical Machinery Factory (General Partnership)

Main Products: Blister Packing Machine,Capsule Filling Machine,Cartoning Machine

Business Type: Manufacturer

Total Employees: 11 - 50 People

Established Year: 2000

Main Markets: Eastern Asia, Southeast Asia, South America, Africa, Mid East

Address: Zhouao Industrial Zone, Zhousong Middle Road, Ruian

Founded in 2000, Ruian Huali Pharmaceutical Machinery Factory integrates research, development, production, sales and service. We are a specialized manufacturer of pharmaceutical machinery and packaging machinery.
At present, our primary products are: DPP series high sealed double aluminum-plastic, double aluminum, and aluminum-plastic automatic packaging machines. These products are suitable for all assortments of specifications of candy tablets, biscuits, dense balls, capsules, food, sugars, and electronic cells.
DZH series automatic Cartoning Machine is for blister, bags, bottle, soap, and other products.
NJP series automatic hard capsule filling machines are suitable for Powder and pellets capsule filling.
If you are interested in any of our products, please contact us for further information. We sincerely welcome customers both at home and abroad to cooperate with us to develop rewarding business partnerships.
My company and Nanjing HUAYAO Packaging Material Co., Ltd. for brothers, specializing in manufacturing Cold-forming aluminum foil, Aluminum blister, Tropical aluminum foil, Strip aluminum foil, Easy tear film and other compound aluminum foil. more
