Centrifugal Dryer
1,Customization accepted
2,Excellent performance
3,Easy operation
4,Wide application
Draining Machine Vegetable Dewatering Centrifugal Dryer
Summary
SSW tripod centrifugal machine is a centrifugal machine used for artificial upper feeding and intermittent operations. It can be divided into two types: filtration type (Type SSW) and sedimentation type (Type SCS) by the separation principle.
Type SSW suits for separating the suspending liquid that contains solid granules more than diameter 0.01mm; the solid phase of the material can be in the granular, crystal or fibrous form as well as be available for dehydrating for materials (including yarn bundle and fabric, etc). The machine has the advantages like compact structure, convenient operation, adjustable process, full sediment abstersion, durable granular phase and strong adaptability. Type SCS suits for liquid defecation, material adhibition, medium filtration and separation solid from liquid, etc. Aside from the weak effect on abstersion, SCS shares the same advantages with SSW.
Application
Both types are widely used in the industry of chemistry, light industry, pharmacy, food, textile, metallurgy and mechanics, etc.
Working principle
There are no anti-explosion structures on the machine, so users are prohibited to separate inflammable and explosive materials if there are no extra requirements. Users have to take on the responsibilities if they separate the inflammable and explosive materials with the assistance of anti-explosion electrical motors. In such a case, users are suggested to follow the steps as below:
1.Ventilation in the field should be strengthened to dilute the density of the inflammable and explosive gas.
2.The antistatic triangle belt should be used in transmission.
3.Metal shovels are prohibited to use in discharging.
4.Frequent checks for abrasion of fraction Wafer between the clutch and braking apparatus are necessary. If abrasion between rivets and metal is found, the fraction wafer should be replaced promptly.
| Model | Dimension(mm) | Power(kw) | Feed capacity(kg/lot) | Rotary speed(r/min) | Weight of machine (kg) |
| SSW-800 | 1690*1380*1000 | 5.5 | ≤120 | 1200 | 1380 |
| SSW-1000 | 1890*1550*1300 | 7.5 | ≤200 | 1000 | 1800 |
| SSW-1200 | 2200*1720*1400 | 11.0 | ≤300 | 800 | 2400 |
Zhejiang Sanshon Machinery Manufacturing Co., Ltd was founded in 1993, located in the most convenient transportation and prosperous economy of Yangtze River delta Shangyu city, Zhejiang. Zhejiang Sanshon Machinery Manufacturing Co., Ltd adjacent to the beauty of the CaoE river, and in less than 5 KM there are three expressways, they are Hangzhou-Ningbo (G92), Changshu-Taizhou (G15w), and 104 national road line , the HangYong high speed railway. Moreover it is less than 100 KM to Hangzhou and Ningbo airport.
It is specialized in manufacturing food processing machinery, which includes fruit & vegetable hot air drying(AD), quick freezing (IQF), vacuum freeze dryer(FD). The company passed ISO9001:2000 quality standard under the efforts of all employees. There are three equipments has been assessed as National New Product. And in 2007, Sanshon was recognized for New and High Technical enterprise in Zhejiang Province.
The company not only in r&d and manufacturing ,but also enjoy the right of import and export. And the machinery from Sanshon has been exported to more than 10 countries, including Vietnam, Thailand, Uzbekistan, Azerbaijan, Iran, Mexico, Venezuela, Peru, Australia, Cyprus, Libya, etc.
Based on more than 20 years’ experience in food process machinery manufacturing, later it established Shaoxing Sanshon Steel Co., Ltd (www.cnsxgg.com) and Shundi foods Co., Ltd(www.shundifoods.com)in Zhejiang and Shanghai. Sanshon now is capable of providing integrated services, including product consultation, design, workshop establishment, equipment manufacturing and installation, training of machine operation in the field of vacuum freeze drying machine (FD), hot air drying (AD) as well as quick frozen (IQF) machines.
Sanshon is well prepared to be a pioneer in the field of dehydration, quick frozen, vacuum freeze drying to contribute to food processing industry!
Term,Conditions
Ordering Information
Payment:
we usually accept T/T,L/C, please send email to negotiate payment term if you can not accept T/T or L/C.
Packing:
iron framework with external plywood and seaworthy package
Please send email for the extra cost of different packing
Delivery Time:
different products will spend different production period: from 30-120 days after 50% advanced payment.
For urgent order, Could be faster, please send email to negotiate
How to make an order?
1,Client make 50% deposit or open LC after receiving our PI
2,Client approve our equipment,
arrange shipment
1,Client effect balance payment before shipment
2. supplier send original documents or telex release the goods
3,quality warranty for 1 year after shipment
| Product Line Name | Production Line Capacity | Actual Units Produced(Previous Year) |
|---|---|---|
| Drying, Freezing and Pre-Treat Machine | Drying Machine, 8 Sets/Month; Freezing Machine, 1 Set/Month; Freeze Drying Machine, 1 Set/Month; Pre-Treatment Machine, 1 Set/Month | Drying Machine, 15 Sets; Freezing Machine, 1 Set; Freeze Drying Machine, 4 Sets; Pre-Treatment Machine, 10 Sets |
| Market | Revenue(Previous Year) | Total Revenue (%) |
|---|---|---|
| North America | confidential | 7.0 |
| South America | confidential | 3.8 |
| Eastern Europe | confidential | 9.5 |
| Southeast Asia | confidential | 9.7 |
| Mid East | confidential | 2.7 |
| Central America | confidential | 3.2 |
| South Asia | confidential | 10.2 |
| Domestic Market | confidential | 53.9 |
| Machine Name | Brand & Model No. | Quantity | Number of Year(s) Used | Condition |
|---|---|---|---|---|
| Plate Shearing Machine | QC12Y-8X3200 | 1 | 10.0 | Acceptable |
| Bending Machine | WE67Y-100/3200 | 1 | 10.0 | Acceptable |
| Milling Machine | DJ-9235 | 1 | 9.0 | Acceptable |
| Lathe | No Information | 3 | 9.0 | Acceptable |
| Welding Machine | WS300 | 12 | 7.0 | Acceptable |
| Machine Name | Brand & Model No. | Quantity | Number of Year(s) Used | Condition |
|---|---|---|---|---|
| Micrometer | 25-50mm | 6 | 3.0 | Acceptable |
| Pressure Meter | No Information | 3 | 3.0 | Acceptable |
| Products Name | MOQ(in the last 12month) |
|---|---|
| Drying Machine | 2 Sets |
| Products Name | Order(in the last 12month) |
|---|---|
| Pre-Treatment Machine, Drying Machine | 22 Sets |
| Products Name | Order(in the last 12month) | Shortest Lead Time |
|---|---|---|
| Drying Machine | 2 Sets | 7 Days |
| Condition: |
New
|
Place of Origin: |
Zhejiang China (Mainland)
|
Brand Name: |
Sanshon
|
| Model Number: |
SSW
|
Type: |
Dryer
|
Voltage: |
380V
|
| Power(W): |
7.5KW
|
Dimension(L*W*H): |
1890*1550*1300mm
|
Certification: |
ISO,CE,UL
|
| Warranty: |
1 Year
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Equipment: |
Centrifugal Dryer
|
| Material of the equipment: |
Stainless steel
|
|
|
|
|
|
|
|
|
|
|
|
|
