Durable grain grader by Japanese agricultural machine manufacturer for sale,Japan TIGER KAWASHIMA price supplier

Durable grain grader by Japanese agricultural machine manufacturer for sale

FOB Price:Price can be negotiated

Production Capacity:10 Piece/Pieces per Month

Payment Terms: US $13,000 - 15,000 / Piece

Update Time:2023-04-26

Contact Supplier

Product Description

* Rice and wheat grain grader
* High-accuracy grading
* Made in Japan

Durable grain grader by Japanese agricultural machine manufacturer for sale

High-accuracy grading is achieved with the large-diameter net

Compatible with a wide variety of layouts

Equipped with a sample slot and signal tower

Product Description

[High-accuracy grading]
In addition to having a mesh tolerance of ±0.03 mm,

high-accuracy grading is achieved with the large, 12-sided grading net.

Powerful, high-accuracy grading is performed.

[Compatible with a wide variety of layouts]
To suit the installation location, the screw-type scrap Conveyor can be placed on

either of the four sides, and the grading net can be exchanged from both the left and

right sides of the machine.

[Sample slot]
When loading, the good rice and scrap rice selection modes can be easily confirmed.

[Signal tower]
A green light signals normal operation, and a flashing red light and buzzer sound

notifies of abnormal motor stoppage.

The machine can be operated safely from a distance.

MX-60- specifications

Total length x total width x total height	2120×645×2395mm
Slot height	2330mm
Good rice outlet height	460mm
Scrap rice spout height	460mm
Maximum processing capacity	3600kg/hour
Power source	Three phase 200V
Motor	Single phase 200V 0.2kW 2units Three phase 200V 0.1kW 1unit
Rotational frequency of grading net	65rpm/50Hz 78rpm/60Hz
Machine body weight	270kg

Kinds of replacement nets(mm)

1.70,1.75,1.80,1.85,1.90,1.95,2.00
2.10,2.20,2.30,2.40,2.50

Transformer specifications (optional extra)

Primary voltage	Three phase 380V•400V • 440V
Secondary voltage	Three phase 200V • 220V
Capacity	2KVA
Width x depth x height	280×320×350mm
Packaging specifications	W330×L360×H440mm Secure, strengthened cardboard packaging
Weight	About 40kg

Company Information

Corporate identity

Head office exterior

Nationwide network

Product development progress

Product lineup

Awards

Product development department

Sheet metal processing department

Assembly department

Powder coating system

Group photo in front of the head office and factory

Condition:	New	Place of Origin:	Japan	Brand Name:	TIGER KAWASHIMA
Model Number:	MX-60-012	Production Capacity:	3600kg/hour	Voltage:	Three phase 200V
Power(W):	200x2units 100x1units	Weight:	270kg	Dimension(LWH):	21206452395mm
Certification:	Please contact us	Warranty:	Please contact us	After-sales Service Provided:	No overseas service provided
