tinplate lid
1.use of safety
2.prime quality
3.SGS,BV test
4.hot selling
Tianjin Xinhai Runda Steel Trade Co.,Ltd
Welcome you anytime!
I know we are not the best, but we will offer you our best with prime quality
tinplate lid
| Standard for temper |
|||
| Chinese Standard |
Japanese Standard |
American Standard |
European Standard |
| GB/T 2520-2008 |
JIS G3303-2008 |
ASTM A623M-06a |
DIN EN10202-2001 |
| T-1 |
T-1 |
T-1 (T49) |
TS230 |
| T1.5 |
— |
— |
— |
| T-2 |
T-2 |
T-2 (T53) |
TS245 |
| T-2.5 |
T-2.5 |
|
TS260 |
| T-3 |
T-3 |
T-3 (T57) |
TS275 |
| T-3.5 |
— |
— |
TS290 |
| T-4 |
T-4 |
T-4 (T61) |
TH415 |
| T-5 |
T-5 |
T-1 (T65) |
TH435 |
| DR-7M |
— |
DR-7.5 |
TH520 |
| DR-8 |
DR-8 |
DR-8 |
TH550 |
| DR-8M |
— |
DR-8.5 |
TH580 |
| DR-9 |
DR-9 |
DR-9 |
TH620 |
| Tinplate specifications |
||||||
| Steel Type |
SPCC, MR |
|||||
| Temper(BA&CA) |
T1~T5 |
|||||
| Coating |
1.1~11.2g/m2 |
|||||
| Thickness and tolerance |
0.15~0.50mm(Tolerance: _+0.01 mm) |
|||||
| Width & tolerance |
300~1000mm (Tolerance: 0~3mm) |
|||||
| Cut length & tolerance |
450~``50mm (Tolerance: 0~3mm ) |
|||||
| COil inside diameter |
420/508mm |
|||||
| Coil Weight |
3~10 MT |
|||||
| Passivation |
311 |
|||||
| Oiling |
DOS |
|||||
| Surface Finish |
Bright, Stone, Silver, Matte |
|||||
| Packaging |
Seaworthy Standard with wooden pallet |
|||||
| Standards Available |
GB/T2520, JIS G3303, ASTM A623M & EN10202 |
|||||
| Special specitications are available on request. |
||||||
| Tin coating weight |
||||||
| Type |
Designation of tin coating weight |
Min.average tin coating weight(g/m2) |
Former Coating Designation |
|||
| Equal tin coating |
1.4/1.4 |
1.2/1.2 |
#15 |
|||
| 2.2/2.2 |
2.0/2.0 |
#20 |
||||
| 2.8/2.8 |
2.45/2.45 |
#25 |
||||
| 5.6/5.6 |
5.05/5.05 |
#50 |
||||
| 8.4/8.4 |
7.55/7.55 |
#75 |
||||
| 11.2/11.2 |
10.1/10.1 |
#100 |
||||
| Differentially Coating |
1.4/2.8 |
1.2/2.45 |
#15/25 |
|||
| 2.2/2.8 |
2.2/2.45 |
#20/25 |
||||
| 2.8/5.6 |
2.45/5.05 |
#25/50 |
||||
| 2.8/8.4 |
2.45/7.55 |
#25/75 |
||||
| 2.8/11.2 |
2.45/10.1 |
#25/100 |
||||
| 5.6/8.4 |
5.05/7.55 |
#50/75 |
||||
| 5.6/11.2 |
5.05/10.1 |
#50/100 |
||||
| 8.4/11.2 |
7.55/10.1 |
#75/100 |
||||
| Surface finish |
||||||
| Surface finish |
Nominal surface roughness (um Ra) |
Characteristic |
||||
| Bright finish |
≤ Q0.35 |
Glazed surface obtained after melting treatment of electrotinned smooth raw materail strip with extremely fine rubstone fingure by processing. |
||||
| Stone finish |
0.25~0.60 |
Glazed surface obtained after melting treatment of electrotinned smooth raw materail stripfeaturing certain rubstone figures. |
||||
| Silver finish |
0.50~1.00 |
Glazed surface obtained after melting treatment of electrotinned smooth raw material strip with rough matt furface. |
||||
|
Matte finish |
0.80~2.50 |
Matt surface of general matt raw material strip without melting treatment. |
||||
Packaging&Transportation
Cerfications:
Contact Information:
| Standard: |
AISI,ASTM,BS,DIN,GB,JIS,AISI,ASTM,BS,DIN,GB,JIS
|
Grade: |
tinplate
|
Width: |
300~1000mm
|
| Thickness: |
0.15~0.50mm
|
Hardness: |
T1
|
Place of Origin: |
TIA,China(Mainland) China (Mainland)
|
| Brand Name: |
tinplate
|
Model Number: |
tinplate
|
Type: |
Tinplate Coil,tinplate
|
| Application: |
Beverage Cans,Milk Cans,Fruit Cans,Tomato Cans,Tuna cans,Edible oil
|
color: |
silver
|
quality: |
prime
|
| certification: |
SGS,BV
|
temper: |
T1-T5
|
coating: |
1.1~11.2g/m2
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
