Full automatic hard candy pouring/forming machine. Different production capacity mode for choice, accept custom-made.
WORKING PROCESS:
Raw material dissolving→Conveying→Filting→Storaging→Constant Syrup converying→Pre-heating→Micro-film vacuum cooking→Mixing with flavor and color→Depositing→Stick Inserting→ Cooling→De-moulding→ Conveying→Packing→Final products
PARAETERS:
MODEL |
JW150 |
JW300 |
JW450 |
JW600 |
Capacity(kg/hr) |
150(kg/hr) |
300(kg/hr) |
450(kg/hr) |
600(kg/hr) |
Max candy weight |
26g |
26g |
26g |
26g |
Lollipop Diameter |
Flat:18-28mm Ball:Max 25mm |
|||
Depositing speed |
55-65n/min |
55-65n/min |
55-65n/min |
55-65n/min |
Stick Specification |
60-100mm |
60-100mm |
60-100mm |
60-100mm |
Compressed air requirement |
0.2m³/min, |
0.2m³/min, |
0.2m³/min, |
0.2m³/min |
Working condition |
Temp:20-25°C |
Temp:20-25°C |
Temp:20-25°C |
Temp:20-25°C |
Total Power |
18kw/380V |
27kw/380V |
34kw/380V |
38kw/380V |
Total Length |
17m |
19m |
19m |
22m |
Total Weight |
3500kg |
4000kg |
lollipop show:
Why choose us?
1. we are the original manufacturer
2. Abundant professional experience in export food machinery
3. Competitive price and the first class service
Jiawang Machinery Co.Ltd, a high tech enterprise, mainly focuses on the food equipment producing, researching and development, such as candy, cookies as well as cake kind etc. From now on, it has successively developed several kinds of food machinery equipment and corresponding technologies. Now the company has become an important professional manufacturer at home and abroad.
