skj105 type
Motor: YL-90L4 2.2 ?????| speed 1,400 rpm
Flat die diameter: 105mm
Membrane pore size: diameter 2.5mm, diameter 3mm, diameter 4mm, 6mm diameter
Grain moisture content: less than 10% of the raw materials
Particle production :80-100kg / h
Body size: length * width * high 60 * 40 * 50 (cm)
Body Weight: 42kg
SKJ120 type
Motor: YL-90L4 2.2 ?????| speed of 1,400 rpm
Flat die diameter: 120mm
Membrane pore size: diameter 2.5mm, diameter 3mm, diameter 4mm, 6mm diameter
Grain moisture content: less than 10% of the raw materials
Particle output :100-120kg / h (
Body size: length * width * high 95 * 40 * 50 (cm)
Body Weight: 70kg
SKJ150 type
Motor: YL132S4 5.5 ?????|
Flat die diameter: 150mm
Membrane pore size: diameter 2.5mm, diameter 3mm, diameter 4mm, 6mm diameter
Grain moisture content: less than 10% of the raw materials
Particle output :150-200kg / h
Body Size: L * W * H 105 * 40 * 40 (cm)
Body weight: 100kg
SKJ200 type
Flat die diameter: 200mm
Membrane pore size: diameter 2.5mm, diameter 3mm, diameter 4mm, 6mm diameter
Grain moisture content: less than 10% of the raw materials
Particle output :200-300kg / h
Body Size: L * W * H 105 * 40 * 40 (cm)
Body weight: 124kg
SKJ250 type
Motor: YL180L6 15 ?????|
Flat die diameter: 250mm
Membrane pore size: diameter 2.5mm, diameter 3mm, diameter 4mm, 6mm diameter
Ping-mode speed: 366r/min
Grain moisture content: less than 10% of the raw materials
Particle output :250-500kg / h (mode pore diameter of 4mm)
Body weight: 175kg
SKJ320 type
Motor: Y225M-6 22 ?????|
Flat die diameter: 320mm
Membrane pore size: diameter 3mm, diameter 4mm, diameter 6mm, 8mm diameter
Ping-mode speed: 300r/min
Grain moisture content: less than 10% of the raw materials
Particle production :700-1200kg / h (mode pore diameter of 4mm)
SKJ420 type
Motor: Y250M-6 37 ?????|
Flat die diameter: 420 mm
Ping-mode speed: 300r/min
Die hole size: diameter 2.5mm, diameter 3mm, diameter 4mm, 6mm diameter, etc.
Grain moisture content: less than 10% of the raw materials
Particle yield :1000-1700 kg / hour (die hole diameter 4mm)
Huaxiang machinery of SKJ series of small and medium domestic feed grain machine output 100-1000 kg / hour to as the principle of circular motion, templates, high quality alloy steel roller with a special treatment, spindle and flat die under the action of the friction force to drive roller rotation, the material in between the roller and template gelatinization temperature, protein coagulation variability, squeezed in roller discharged from the die hole, made of particles sent out by the rejection trays outside the machine, particle length adjustable through the incision . In the granulation process without adding water, without drying, by the natural warming up to 70-90 degrees, allows starch gelatinization, particle maturation within the deep, smooth surface and high hardness can be long-term storage, is a rabbit, fish , chickens, pigs, sheep, cattle feed plant specialized households and small and medium reduces breeding costs, and improving economic efficiency ideal equipment, the preferred model.
Note: The machine in the processing of pellets of natural temperature of 70 degrees, to various additives drugs, nutritional losses minimal. Particles smooth surface, moderate hardness, degree of internal curing deep through. Can kill to pathogenic microorganisms and parasites, while the guarantee of feed quality, can be used for rabbit, chicken, ducks, geese, fish, pigs, aquatic products. Granular machine templates and high alloy roller made of wear-resistant materials refined, with long service life, reasonable structure and durable, etc.
Huaxiang particle machine as follows:
(1) two-phase particle machine:
105 feed grain machine: output 80-100kg / h, matching motor power: 2.2kw 4 ?o§
120 box feed grain machine: Yield 100-120Kg / h, matching motor power: 2.2kw 4 ?o§
Feed particles 120 directly connected machine: output 100-120Kg / h, matching motor power: 2.2kw 4 ?o§
(2) three-phase electric particle machine:
150 box feed grain machine: Yield 150-200Kg / h, motor power: 5.5KW 4 ?o§
150 axis feed particle machines: production of 150-200Kg / h, motor power: 5.5KW 4 ?o§
200 box feed grain machine: Yield 250-300Kg / h, motor power: 11KW 4 ?o§
200 axis feed particle machines: production of 250-300Kg / h, motor power: 11KW 4 ?o§
250 axis feed particle machines: production of 300-500Kg / h, motor power: 15KW 6 ?o§
(3) ring mold feed grain machine
200 ring mold feed grain machine: output :500-800Kg / h, motor power: 15KW 6 ?o§
250 ring mold feed grain machine: output :600-1000Kg / h, motor power: 22KW 6 ?o§
This is a part of product manufacturers a simple explanation, in addition to manufacturers to meet the needs of different users is also designed with dual-use diesel particulate machine, straw fuel particle machine, wood pellets machine use of biomass energy particle machine, pellet mill. Manufacturers to meet the market need the latest mass production of organic fertilizer granulation machine, organic fertilizer production equipment, organic fertilizer production line has been put into production throughout the country. We produce organic fertilizer equipment manufacturing finished products for the spherical, smooth, beautiful and practical, is the organic fertilizer manufacturers, the best choice! "Huaxiang" friends who would like to sincerely for the service, to provide you with the most suitable products is our constant commitment. Welcome friends to visit the discussion! Zhang Qiu Huaxiang Machinery Factory Shandong SKJ series of small-scale domestic production of feed grain machine output 50-100 kg / hour, with circular motion as the principle, templates, high quality alloy steel roller with a special treatment, spindle and flat die under the action of the friction force, drive roller rotation, the material in between the roller and template gelatinization temperature, protein coagulation variability, squeezed in roller discharged from the die hole, made of particles sent out by the rejection trays outside the machine, through the incision adjustable particle length.
In the granulation process without adding water, without drying, by the natural temperature of 70 degrees, make starch gelatinization, particle internal curing the deep, smooth surface, high hardness, can be long-term storage, is a rabbit, fish, chicken , pigs, sheep, cattle specialized households and small and medium sized feed mills reduce farming costs, improve the economic efficiency of an ideal device, the preferred model.
Note: The machine in the processing of pellets of natural temperature of 70 degrees, to various additives drugs, nutritional losses minimal. Particles smooth surface, moderate hardness, degree of internal curing deep through. Can kill to pathogenic microorganisms and parasites, while the guarantee of feed quality, can be used for rabbit, chicken, ducks, geese, fish, pigs, aquatic products.
