Forming-Cutting Machine

FOB Price:Price can be negotiated

Payment Terms: FOB

Update Time:2015-06-04

Contact Supplier

Product Description

The forming-cutting machine works on the principle of vacuum hot-compression forming. The roll material will be pre-heated, formed, cooled and cut into single blister. It’s designed with the integration of machine, electricity and gas. It is controlled by PLC man-machine interface system and it is easy to operate. The time of heating, forming and transportation can be enforced by stepless speed regulation. It has such advantages as high speed of forming and cutting. Since the machine adopts the fully closed structure, it’s safe to operate.

The main technical parameters：

Number	project	description
1	Cutting times	10-50times/minute（It depends on both the shape of the production and the thickness of the materials）
2	Maximum forming area and depth	34515230（LWH）mm
3	power supply	Power supply: the three-phase four-wire 380V 50hz（220v 60Hz）
4	Main Engine	6kw
5	Raw materials	PVC,PET,PP,PS……
6	Appearance Size	27107201600（LWH）mm
7	Overall weight	1600KG

Advantages:

1. It is combined cutting with forming, so it reduces transit link.

2. It consumes low power and it’s easy to operate.

3. The molding cylinder uses 4 balance guide pins in order to reduce the attrition of the cylinder and increase the service life.

4. Quick speed of pulling pieces. So as to send pieces accurately.

5. Quick mould- changing speed and quick replacing institutions in forming mechanism design.

6. Rapid parameter design and adjustment due to the computerized control system and touch screen operation.
