FUHN-950C Automatic Roll Die-cutting & Creasing Machine,China price supplier

FUHN-950C Automatic Roll Die-cutting & Creasing Machine

FOB Price:Price can be negotiated

Update Time:2017-08-21

Product Description

FUHN-950 is an ideal and professional machine in die-cutting，creasing，embossing and full-stripping various PE coated paper, normal paper, corrugating paper and plastic material. It applies to paper cup,paper box,medical package,wine package,food package and other environmental protection products.It adopts micro-computer,HMI,servo positioning,alternating current frequency converter,automatic counting,photoelectric rectifying,pneumatic lock cutting plate,electromagnetic clutch,centralized oil lubrication,,overload protection and distinctive gearing.All of these is the guarantee of steady pressure,precise positioning,smooth running,safety and reliability operation.

Type	FUHN-950
Cut Precision:	± 0.10mm
Production capacity	90-140 times/min
Maximum cutting size:	950 x540mm
Max Paper Convey Width:	950mm
Suitable Material:	100-800g/m2
Maximum Pressure:	250T
Total Power:	11KW
Total Weight:	6.5T
Overall Dimension:	4200 x 2100 x 1850 mm
Working Air Source:	Air pressure 0.5-0.7Mpa (Need to buy compressor)

Other Products

FUHN-N12 Paper Cup Forming Machine

FUHN-950C Automatic Roll Die-cutting & Creasing Machine

Company Profile

Name: Fuhang Machine Company

Main Products: plastic machine,lable machine,printing machine,packing machine

Business Type: Trade

Total Employees: < 20

Established Year: 1990

Main Markets: Eastern Asia,

Address: Room1504,block 10,Zhongrui Jing yuan ,Anyang street, Ruian City

Established in 1990, Ruian Fuhang Machine Factory has been the symbol of high quality and excellent service in machinery areas for many years. Our factory is located in SHANGWANG INDUSTRIAL，Ruian City, zhejiang province , China. The nearest airport is Wenzhou airport, It is about 40 km away from Wenzhou Airport. Our office address is Room 1504, Block 10, Zhongrui jingyuan , anyang street , ruian city, zhejiang province, China.

We have four factoies Manufacturing machines and cooperation with more than 100 factories . Our products like gravure printing machine , slitting machine, forming machine , flexo printing machine, paper bag machine , paper tube making machine,label machine etc. Accredited by ISO9001, CE certificates.
