Full Automatic Glass Bottle Liquid Bottle Filling Machine with twist-off Capping System

FOB Price:Price can be negotiated

Production Capacity:60 sets/year

Payment Terms: T/T L/C

Update Time:2021-03-26

Contact Supplier

Product Description

Detailed Product Description

Full Automatic Glass Bottle Liquid Bottle Filling Machine with twist-off Capping System

Quick Detail:

High Capacity,

Availabel bottle volume: 150ml-1500ml

No Bottle No Filling,no capping

High Accuracy

Easy To Operate

Description:

Glass bottle liquid filling and capping machine 2-in-1

1. The Fill Machine construction in Stainless Steel #304.

2. Each rotary Lobe pump is driven by an individual motor for high accuracy liquid filling.

3. PLC combined with touch screen control system. Filling volume can be adjusted easily and separately.

4. No change parts are required for different bottle sizes.

5. Diving type filling system prevents spillage during filling.

6. No bottle, no filling safety device.

7.20 job memory for easy recall.

8. You can choose A type, B type or C type for different filling range.

Applications:

This bottle filling machine is designed for handle from water-thin to high viscosity product, especially for viscid and foaming product in chemical, food, beverage, pharmaceutical, and biotechnology industry.

Specifications:

Model	BGF18-6	BGF24-8	BGF32-10
Filling Volume (ml)	A Type: 30-500; B: 100-1000ml; C Type: 200-5000
Power	3.5kw-5.5kw
Max. Filling Speed	60B/min.	100B/min.	150B/min.
Filling Nozzles	18	24	32
